- Page 1 00-2452 120’ Honda CR-V 2007»2012 624-120x...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 624-120x Included Material Inkluderat material...
- Page 5 Towbar installation diagram Dragkrok installationsdiagram...
-
Page 6: Fitting Instructions
624-120x Fitting instructions 1.Loose the bottom fixing points of the bumper. 2. Place the pieces A and B at both sides of the chassis and fix (without tightening) on the points 1 with M10x1,25x35 bolts, flat washers and spring washers. 3.Do a cut at the edge of the bumper to fix at point 3 as described on picture. - Page 7 Sågningsschema över stötfångaren...
- Page 8 624-120x Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 624-120x Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 2200 kg D= 10,79 kN S= 100 kg...
