- Page 1 00-2085 120’ Renault Modus 2005» Renault Grand Modus 2009» 652-230x...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 652-230x Included Material Inkluderat material Elementos de unión de la bola Fixing itemso ft he coupling head 2x M12 Delar för dragkrokens fäste Elementid i unione della sfera Befestigungselemented er Kugel 2x 12 x 70 (8.8) Elementos ques e aportan Provided items Medföljande delar Elementic he si forniscono...
- Page 5 Towbar installation diagram Dragkrok installationsdiagram...
-
Page 6: Fitting Instructions
652-230x Fitting instructions 1.Dismantle the bumper and remove the stickers from the fitting points if there is any. *Note : it is possible to put the towbar without removing the bumper. 2.Fix the arms 1 throught the outside chassis to the fitting points A, through the middle of the bolts 10x100, flat washers 30 diameter flat washers, nuts with base and bushings, (58 mm at the right side and 62 mm to the left side). - Page 8 652-230x Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 652-230x Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 1100 kg D= 6,54 kN S= 75 kg...
