- Page 1 00-1191 120’ Peugeot 307 Kombi 2002»2009 647-1500...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 647-1500 Included Material Inkluderat material 1xM10 x 70 DIN 931 (8.8) Elementos de unión de la bola Fixing items of the coupling head 1xM10 x 65 DIN 931(8.8) Delar för dragkrokens fäste. Elementid i unione della sfera 2xM10 DIN 985...
- Page 5 Towbar installation diagram Dragkrok installationsdiagram...
-
Page 6: Fitting Instructions
647-1500 Fitting instructions 1. Loosen bolts from the inside chassis. 2. Loosen bolts from the bumper supports (coinciding with points 4) and place ones joined M8x40. 3. Introduce plates A joined to both sides of the chassis and fix at these bolts (points 4) using flat washers and M10 nuts. - Page 7 RECO RTE DELPARAGOLPES SÅGNING I STÖTFÅNGAREN COUP E DU PARE-CHOC S Ä Recortar la zona sombreada. Make a reces son the marked area. Gör en utskärning i den markerade ytan. Den Bereich im Schatten ausschneiden. Roccortare la zona con l´ombra. Gör en utskärning i den markerade ytan 90 mm.
- Page 8 647-1500 Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 647-1500 Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 1500 kg D= 8,44 kN S= 75 kg...
