- Page 1 00-1068 120’ Toyota Hi-Lux 1997»2005 664-0226...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 664-0226 Included Material Inkluderat material Elementos de unión de la bola Fixing itemso ft he coupling head Delar för dragkrokens fäste 2x M16x1,5 Elementid i unione della sfera Befestigungselemented er Kugel 2x 16x1,5x50 Elementos ques e aportan Provided items Medföljande delar Elementic he si forniscono ZumL ieferumfang gehörendesM aterial...
- Page 5 Towbar installation diagram Dragkrok installationsdiagram...
-
Page 6: Fitting Instructions
664-0226 Fitting instructions 1. Remove the spare wheel and the stage if there is any. 2. Place two 16x56 mm. bushings by outside chassis at points D. Place bolts and washers at the bush- ings through the opening at the crossbeam. Place lateral supports outside of the chassis make them coincide with the origin hold using the bolts from each point. - Page 8 664-0226 Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 664-0226 Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 2300 kg D= 12,10 kN S= 100 kg...
