Replaceable Electrical Parts List (Cont.)
Component Tektronix Serial No.
Number Part Number Effective
A2U31 156–6172–00
A2U31 156–6345–00 671-1927-03
A2U31 156–6172–00
A2U31 156–6345–00 671-2507-03
136–1005–00
A2U32 156–3019–00
A2U34 156–6172–00
A2U34 156–6345–00 671-1927-03
A2U34 156–6172–00
A2U34 156–6345–00 671-2507-03
136–1005–00
A2U40 156–1291–00
A2U41 156–1272–00
A2U42 156–1272–00
A2U50 156–1207–00
A2U50 156–2263–00 671-1927-03
A2U50 156–1207–00
A2U50 156–2263–00 671-2507-03
A2U106 156–0368–03
A2U106 156–2289–00 671-1927-03
TSG 200 NTSC Generator Instruction Manual
Serial No.
Discont'd Name & Description
671-1927-02 IC,CONVERTER:BIPOLAR,D/A,10 BIT,20MHZ,CURRENT
OUTPUT,0.5LSBINL,TDC1041R3C1,PLCC28–1,TUBE
IC,CONVERTER:BIPOLAR,D/A,12 BIT,80MHZ,TTL
INPUT,W/LATCHES,CURRENT OUT,REFERENCE,
AD9713BAP,PLC
671-2507-02 IC,CONVERTER:BIPOLAR,D/A,10 BIT,20MHZ,CURRENT
OUTPUT,0.5LSBINL,TDC1041R3C1,PLCC28–1,TUBE
IC,CONVERTER:BIPOLAR,D/A,12 BIT,80MHZ,TTL
INPUT,W/LATCHES,CURRENT OUT,REFERENCE,
AD9713BAP,PLC
*MOUNTING PARTS*
SOCKET,PLCC:
*END MOUNTING PARTS*
IC,LINEAR:BIPOLAR,VOLTAGE REFERENCE,1.235V,
1.0%,150PPM,SHUNT,MICROPOWER,LM385BZ–1.2,TO
–92
671-1927-02 IC,CONVERTER:BIPOLAR,D/A,10 BIT,20MHZ,CURRENT
OUTPUT,0.5LSBINL,TDC1041R3C1,PLCC28–1,TUBE
IC,CONVERTER:BIPOLAR,D/A,12 BIT,80MHZ,TTL
INPUT,W/LATCHES,CURRENT OUT,REFERENCE,
AD9713BAP,PLC
671-2507-02 IC,CONVERTER:BIPOLAR,D/A,10 BIT,20MHZ,CURRENT
OUTPUT,0.5LSBINL,TDC1041R3C1,PLCC28–1,TUBE
IC,CONVERTER:BIPOLAR,D/A,12 BIT,80MHZ,TTL
INPUT,W/LATCHES,CURRENT OUT,REFERENCE,
AD9713BAP,PLC
*MOUNTING PARTS*
SOCKET,PLCC:
*END MOUNTING PARTS*
IC,LINEAR:BIFET,OP–AMP,DUAL,LOW
POWER,TL062CP,DIP08.3
IC,LINEAR:BIPOLAR,OP–AMP,DUAL,HIGH OUTPUT
DRIVE,LOW NOISE,NE5532N,DIP08.3
IC,LINEAR:BIPOLAR,OP–AMP,DUAL,HIGH OUTPUT
DRIVE,LOW NOISE,NE5532N,DIP08.3
671-1927-02 IC,LINEAR:BIPOLAR,VOLTAGE REGULATOR,
NEGATIVE,–12V,500MA,3%,LM320H–12,TO–39
IC,LINEAR:BIPOLAR,VOLTAGE REGULATOR,
NEGATIVE,–12V,100MA,4%,MC79L12ACP,TO–92
671-2507-02 IC,LINEAR:BIPOLAR,VOLTAGE REGULATOR,
NEGATIVE,–12V,500MA,3%,LM320H–12,TO–39
IC,LINEAR:BIPOLAR,VOLTAGE REGULATOR,
NEGATIVE,–12V,100MA,4%,MC79L12ACP,TO–92
671-1927-02 IC,DIGITAL:ECL,TRANSLATOR,QUAD
TTL–TO–ECL,10124,DIP16.3,TUBE
IC,DIGITAL:ECL,TRANSLATOR,QUAD TTL–TO–ECL,
10H124,DIP16.3,TUBE
TSG 200 — Replaceable Electrical Parts
Mfr. Code
07933
24355
07933
24355
00779
27014
07933
24355
07933
24355
00779
01295
01295
01295
04713
04713
04713
04713
04713
04713
Mfr. Part Number
TDC1041R3C1
AD9713BAP
TDC1041R3C1
AD9713BAP
3–821581–1
LM385BZ–1.2
TDC1041R3C1
AD9713BAP
TDC1041R3C1
AD9713BAP
3–821581–1
TL062CP
NE5532P
NE5532P
MC79L12ACG
MC79L12ACP
MC79L12ACG
MC79L12ACP
MC10124P
MC10H124P
8–23
