Tektronix TSG200 Instruction Manual page 94

Replaceable Electrical Parts List (Cont.)
Component Tektronix Serial No.
Number Part Number Effective
A2R62 322–3296–00
A2R63 311–0633–00
A2R64 322–3056–01
A2R65 322–3085–00
A2R66 322–3001–00
A2R67 317–0036–00
A2R68 322–3193–00
A2R68 322–3193–00
A2R69 322–3126–00
A2R69 322–3126–00
A2R70 322–3226–00
A2R71 322–3213–00
A2R71 322–3213–00
A2R72 322–3213–00
A2R72 322–3277–00 671-1927-03
A2R72 322–3213–00
A2R72 322–3277–00 671-2507-03
A2R73 317–0036–00
A2R101 307–0648–00
A2R102 322–3039–00
A2R103 322–3289–00
A2R104 322–3039–00
A2R105 322–3222–00
A2R106 322–3404–00
A2R107 322–3404–00
A2R108 322–3222–00
A2R109 322–3289–00
A2R110 322–3318–00
A2R112 322–3273–00
A2R113 322–3239–00
A2R114 322–3418–00
A2R115 322–3039–00
A2R116 322–3289–00
A2R117 322–3039–00
A2R118 322–3222–00
A2R119 322–3289–00
A2R120 322–3239–00
A2R121 322–3280–00
TSG 200 NTSC Generator Instruction Manual
Serial No.
Discont'd Name & Description
RES,FXD,FILM:11.8K OHM,1%,0.2W,TC=T0
RES,VAR,NONWW:TRMR,5K OHM,0.5W
RES,FXD,FILM:37.4 OHM,0.5%,0.2W,TC=T0
RES,FXD:METAL FILM,75 OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM,10 OHM,1%,0.2W,TC=100
RES,FXD,CMPSN:3.6 OHM,5%,0.125W
671-1927-02 RES,FXD:METAL FILM,1K OHM,1%,0.2W,TC=100
671-2507-02 RES,FXD:METAL FILM,1K OHM,1%,0.2W,TC=100
671-1927-02 RES,FXD,FILM:200 OHM,1%,0.2W,TC=T0
671-2507-02 RES,FXD,FILM:200 OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,2.21K OHM,1%,0.2W,TC=100
671-1927-02 RES,FXD,FILM:1.62K OHM,1%,0.2W,TC=T0
671-2507-02 RES,FXD,FILM:1.62K OHM,1%,0.2W,TC=T0
671-1927-02 RES,FXD,FILM:1.62K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:7.5K OHM,1%,0.2W,TC=T0
671-2507-02 RES,FXD,FILM:1.62K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:7.5K OHM,1%,0.2W,TC=T0
RES,FXD,CMPSN:3.6 OHM,5%,0.125W
RES NTWK,FXD,FI:8,100 OHM,2%,0.125 W
RES,FXD,FILM:24.9 OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,10K OHM,1%,0.2W,TC=100
RES,FXD,FILM:24.9 OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,2K OHM,1%,0.2W,TC=100
RES,FXD,FILM:158K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:158K OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,2K OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM,10K OHM,1%,0.2W,TC=100
RES,FXD,FILM:METAL FILM,20K OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM,6.81K OHM,1%,0.2W,TC=100
RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,221K OHM,1%,0.2W,TC=100
RES,FXD,FILM:24.9 OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,10K OHM,1%,0.2W,TC=100
RES,FXD,FILM:24.9 OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,2K OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM,10K OHM,1%,0.2W,TC=100
RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:8.06K OHM,1%,0.2W,TC=T0
TSG 200 — Replaceable Electrical Parts
Mfr. Code
57668
32997
57668
91637
91637
50139
91637
91637
91637
91637
91637
57668
57668
57668
57668
57668
57668
50139
11236
91637
91637
91637
91637
91637
91637
91637
91637
91637
91637
91637
57668
91637
91637
91637
91637
91637
91637
91637
Mfr. Part Number
CRB20 FXE 11K8
3329H–L58–502
CRB20 DXE 37E4
CCF501G75R00F
CCF501G10R00F
BB36G5
CCF501G10000F
CCF501G10000F
CCF501G200ROF
CCF501G200ROF
CCF501G22100F
CRB20 FXE 1K62
CRB20 FXE 1K62
CRB20 FXE 1K62
CRB20 FXE 7K50
CRB20 FXE 1K62
CRB20 FXE 7K50
BB36G5
761–3–R100
CCF50–2–G24R90FT
CCF50G10001F
CCF50–2–G24R90FT
CCF501G20000F
CCF50–2F15802F
CCF50–2F15802F
CCF501G20000F
CCF50G10001F
CCF501G20001F
CCF50–2–G68100F
CCF501G30100F
CRB20 FXE 221K
CCF50–2–G24R90FT
CCF50G10001F
CCF50–2–G24R90FT
CCF501G20000F
CCF50G10001F
CCF501G30100F
CCF501G80600F
8–19
