Tektronix TSG200 Instruction Manual page 92

Replaceable Electrical Parts List (Cont.)
Component Tektronix Serial No.
Number Part Number Effective
A2L4 108–0538–00
A2L8 120–1180–00
A2L9 114–0415–00
A2L10 114–0366–00
A2L11 114–0367–00
A2L12 114–0369–00
A2L14 120–1180–00
A2L15 114–0415–00
A2L16 114–0366–00
A2L17 114–0367–00
A2L18 114–0369–00
A2L28 108–0245–00
A2L29 108–0245–00
A2L30 108–0538–00
A2L30 108–0538–00
A2L60 108–1263–00
A2L70 108–1263–00
A2L605 108–1263–00
A2LF1 119–1946–00
A2P6 131–0993–02
A2P7 131–0993–02
A2P40 131–0993–02
A2P50 131–0993–02
A2P60 131–0993–02
A2P70 131–0993–02
A2P108 131–0993–05
A2P122 198–5783–00
A2P602 131–0993–02
A2P603 131–0993–02
A2P604 131–0993–05
A2P606 131–0993–05
A2P613 131–0993–05
A2P614 131–0993–05
A2Q1 151–1121–00
A2Q2 151–1025–00
A2Q30 151–0190–00
TSG 200 NTSC Generator Instruction Manual
Serial No.
Discont'd Name & Description
INDUCTOR,FXD:CUSTOM,POWER,2.7UH
TRANSFORMER,RF:VARIABLE
INDUCTOR,VAR:775–925NH
INDUCTOR,VAR:2.40–2.70UH
INDUCTOR,VAR:2.70–3.30UH
INDUCTOR,VAR:2.18–2.3UH
TRANSFORMER,RF:VARIABLE
INDUCTOR,VAR:775–925NH
INDUCTOR,VAR:2.40–2.70UH
INDUCTOR,VAR:2.70–3.30UH
INDUCTOR,VAR:2.18–2.3UH
INDUCTOR,FXD:CUSTOM,POWER,3.9UH
INDUCTOR,FXD:CUSTOM,POWER,3.9UH
671-1927-02 INDUCTOR,FXD:CUSTOM,POWER,2.7UH
671-2507-02 INDUCTOR,FXD:CUSTOM,POWER,2.7UH
INDUCTOR,FXD:POWER,10UH
INDUCTOR,FXD:POWER,10UH
INDUCTOR,FXD:POWER,10UH
FILTER,RFI:1A,250V,400HZ W/PC TERMINAL
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
BUS,CONDUCTOR:SHUNT ASSEMBLY,GREEN
WIRE,SET ELEC:TSG111/TSG121/TSG131
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
CONN,BOX:SHUNT,FEMALE,RED,JUMPER
BUS,CONDUCTOR:SHUNT ASSEMBLY,GREEN
BUS,CONDUCTOR:SHUNT ASSEMBLY,GREEN
BUS,CONDUCTOR:SHUNT ASSEMBLY,GREEN
BUS,CONDUCTOR:SHUNT ASSEMBLY,GREEN
TRANSISTOR,PWR:MOS,N–CH,60V,0.5A,3.0
OHM,VN0106N3/VN0606L,TO–92
TRANSISTOR,SIG:JFET,N–CH,6V,15MA,4.5MS,AMPLIFI
ER,J304/PN4416,TO–92
TRANSISTOR,SIG:BIPOLAR,NPN,40V,200MA,300MHZ,A
MPLIFIER,2N3904,TO–92
TSG 200 — Replaceable Electrical Parts
Mfr. Code
0JR03
54937
54937
54937
54937
54937
54937
54937
54937
54937
54937
0JR03
0JR03
0JR03
0JR03
TK2058
TK2058
TK2058
0GV52
00779
00779
00779
00779
00779
00779
00779
TK1547
00779
00779
00779
00779
00779
00779
17856
04713
04713
Mfr. Part Number
108–0538–00
500–3910
500–3901
114–0366–00
500–3895
500–3896
500–3910
500–3901
114–0366–00
500–3895
500–3896
108–0245–00
108–0245–00
108–0538–00
108–0538–00
TSL0707–100K1R9
TSL0707–100K1R9
TSL0707–100K1R9
FX326–1/02–K–D–T
1–850100–O
1–850100–O
1–850100–O
1–850100–O
1–850100–O
1–850100–O
850100–5
198–5783–00
1–850100–O
1–850100–O
850100–5
850100–5
850100–5
850100–5
VN0606L
SPF3036
2N3904
8–17
