Tektronix TSG200 Instruction Manual page 90

Replaceable Electrical Parts List (Cont.)
Component Tektronix Serial No.
Number Part Number Effective
A2C680 281–0893–00 671-1927-03
A2C680 281–0893–00 671-2507-03
A2C681 281–0893–00 671-1927-03
A2C681 281–0893–00 671-2507-03
A2CR1 152–0141–02
A2CR2 152–0141–02
A2CR10 152–0601–00
A2CR11 152–0601–00
A2CR12 152–0601–00
A2CR13 152–0601–00
A2CR40 152–0601–00
A2CR50 152–0601–00
A2CR60 152–0670–00
A2CR70 152–0670–00
A2CR71 152–0964–00
A2CR72 152–0964–00
A2CR600 152–0601–00
A2CR606 152–0676–00
A2CR608 152–0141–02
A2CR609 152–0141–02
A2CR610 152–0141–02
A2F1 159–0031–00
344–0329–00
A2F600 159–0021–00
344–0329–00
A2J6 131–0608–00
TSG 200 NTSC Generator Instruction Manual
Serial No.
Discont'd Name & Description
CAP,FXD,CERAMIC:MLC,4.7PF,+/–0.5PF,100V,AXIAL,MI
CAP,FXD,CERAMIC:MLC,4.7PF,+/–0.5PF,100V,AXIAL,MI
CAP,FXD,CERAMIC:MLC,4.7PF,+/–0.5PF,100V,AXIAL,MI
CAP,FXD,CERAMIC:MLC,4.7PF,+/–0.5PF,100V,AXIAL,MI
DIODE,SIG:ULTRA FAST,40V,150MA,4NS,2PF,
1N4152,DO–35,T&R
DIODE,SIG:ULTRA FAST,40V,150MA,4NS,2PF,1N4152,
DO–35,T&R
DIODE,RECT:ULTRA FAST,150V,25NS,35A
IFSM,MUR120
DIODE,RECT:ULTRA FAST,150V,25NS,35A
IFSM,MUR120
DIODE,RECT:ULTRA FAST,150V,25NS,35A
IFSM,MUR120
DIODE,RECT:ULTRA FAST,150V,25NS,35A
IFSM,MUR120
DIODE,RECT:ULTRA FAST,150V,25NS,35A
IFSM,MUR120
DIODE,RECT:ULTRA FAST,150V,25NS,35A
IFSM,MUR120
DIODE,RECT:SCHTKY,40V,3A,1N5822
DIODE,RECT:SCHTKY,40V,3A,1N5822
DIODE,SIG:ULTRA FAST,50V,200MA,4NS,2.5PF,1N4150
DIODE,SIG:ULTRA FAST,50V,200MA,4NS,2.5PF,1N4150
DIODE,RECT:ULTRA FAST,150V,25NS,35A
IFSM,MUR120
DIODE,RECT:400V,3A,125A IFSM,1VF AT 3A,1N5625
DIODE,SIG:ULTRA
FAST,40V,150MA,4NS,2PF,1N4152,DO–35,T&R
DIODE,SIG:ULTRA
FAST,40V,150MA,4NS,2PF,1N4152,DO–35,T&R
DIODE,SIG:ULTRA
FAST,40V,150MA,4NS,2PF,1N4152,DO–35,T&R
FUSE,CARTRIDGE:3AG,0.4A,250V,SLOW BLOW
*MOUNTING PARTS*
CLIP,ELECTRICAL:FUSE,5 X 20MM
(QUANTITY 2)
*END MOUNTING PARTS*
FUSE,CARTRIDGE:3AG,2A,250V,FAST BLOW
*MOUNTING PARTS*
CLIP,ELECTRICAL:FUSE,5 X 20MM
(QUANTITY 2)
*END MOUNTING PARTS*
CONN,TERMINAL:MALE,STR,0.025 X 0.137 GOLD,BRZ
(QUANTITY 3)
TSG 200 — Replaceable Electrical Parts
Mfr. Code
04222
04222
04222
04222
01295
01295
04713
04713
04713
04713
04713
04713
04713
04713
TK2262
TK2262
04713
14936
01295
01295
01295
71400
61857
71400
61857
22526
Mfr. Part Number
SA102A4R7DAA
SA102A4R7DAA
SA102A4R7DAA
SA102A4R7DAA
1N4152R
1N4152R
MUR115
MUR115
MUR115
MUR115
MUR115
MUR115
1N5822
1N5822
DM 308BT100SP–4150
DM 308BT100SP–4150
MUR115
1N5625
1N4152R
1N4152R
1N4152R
MDL 4/10
H–0011–2
AGC–2
H–0011–2
48283–018
8–15
