Tektronix TSG200 Instruction Manual page 96

Replaceable Electrical Parts List (Cont.)
Component Tektronix Serial No.
Number Part Number Effective
A2R376 322–3034–00 671-2507-03
A2R600 322–3289–00
A2R601 322–3289–00
A2R604 307–0526–00
A2R605 322–3056–01
A2R605 322–3085–00 671-1927-03
A2R605 322–3056–01
A2R605 322–3085–00 671-2507-03
A2R606 322–3085–07
A2R640 322–3193–00
A2R641 322–3280–00
A2R642 307–0650–00
A2R645 315–0391–00
A2R646 315–0332–00
A2R647 307–0650–00
A2R648 307–0650–00
A2R649 311–0633–00
A2R650 311–0634–00
A2R651 322–3085–07
A2R653 322–3193–00
A2R654 322–3133–00
A2R655 311–0633–00
A2R656 322–3085–07
A2R657 322–3296–00
A2R658 322–3224–00
A2R659 322–3318–00
A2R660 321–0673–07
A2R661 321–0962–07
A2R662 322–3222–00
A2R663 322–3246–00
A2R664 322–3411–00
A2R665 322–3411–00
A2R666 322–3275–00
A2R667 322–3289–00
A2R668 322–3085–00 671-1927-03
A2R668 322–3085–00 671-2507-03
A2R669 322–3085–00 671-1927-03
A2R669 322–3085–00 671-2507-03
TSG 200 NTSC Generator Instruction Manual
Serial No.
Discont'd Name & Description
RES,FXD,FILM:22.1 OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM,10K OHM,1%,0.2W,TC=100
RES,FXD:METAL FILM,10K OHM,1%,0.2W,TC=100
RES,NTWK:THICK FILM,(5)510 OHM,10%,0.125W
EACH,TC=100
671-1927-02 RES,FXD,FILM:37.4 OHM,0.5%,0.2W,TC=T0
RES,FXD,FILM:75 OHM,1%,0.2W,TC=100 PPM
671-2507-02 RES,FXD,FILM:37.4 OHM,0.5%,0.2W,TC=T0
RES,FXD,FILM:75 OHM,1%,0.2W,TC=100 PPM
RES,FXD:METAL FILM,75 OHM,0.1%,0.2W,TC=25
RES,FXD:METAL FILM,1K OHM,1%,0.2W,TC=100
RES,FXD,FILM:8.06K OHM,1%,0.2W,TC=T0
RES NTWK,FXD,FI:9,2.7K OHM,5%,0.150W
RES,FXD,FILM:390 OHM,5%,0.25W
RES,FXD,FILM:3.3K OHM,5%,0.25W
RES NTWK,FXD,FI:9,2.7K OHM,5%,0.150W
RES NTWK,FXD,FI:9,2.7K OHM,5%,0.150W
RES,VAR,NONWW:TRMR,5K OHM,0.5W
RES,VAR,NONWW:TRMR,500 OHM,0.5W
RES,FXD:METAL FILM,75 OHM,0.1%,0.2W,TC=25
RES,FXD:METAL FILM,1K OHM,1%,0.2W,TC=100
RES,FXD,FILM:237 OHM,1%,0.2W,TC=T0
RES,VAR,NONWW:TRMR,5K OHM,0.5W
RES,FXD:METAL FILM,75 OHM,0.1%,0.2W,TC=25
RES,FXD,FILM:11.8K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:2.1K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:METAL FILM,20K OHM,1%,0.2W,TC=100
RES,FXD,FILM:17K OHM,0.1%,0.125W,TC=T9
RES,FXD,FILM:8K OHM,0.1%,0.125W,TC=T9
RES,FXD:METAL FILM,2K OHM,1%,0.2W,TC=100
RES,FXD,FILM:3.57K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:187K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:187K OHM,1%,0.2W,TC=T0
RES,FXD,FILM:7.15K OHM,1%,0.2W,TC=T0
RES,FXD:METAL FILM,10K OHM,1%,0.2W,TC=100
RES,FXD,FILM:75 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:75 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:75 OHM,1%,0.2W,TC=100 PPM
RES,FXD,FILM:75 OHM,1%,0.2W,TC=100 PPM
TSG 200 — Replaceable Electrical Parts
Mfr. Code
91637
91637
91637
11236
57668
57668
57668
57668
91637
91637
91637
11236
50139
50139
11236
11236
32997
32997
91637
91637
91637
32997
91637
57668
91637
91637
07716
57027
91637
57668
91637
91637
57668
91637
57668
57668
57668
57668
Mfr. Part Number
CCF50–22R1F–R36
CCF50G10001F
CCF50G10001F
750–61–R510 OHM OR
770–61R510
CRB20 DXE 37E4
CRB20T68EFX75R0
CRB20 DXE 37E4
CRB20T68EFX75R0
CCF502–C75ROOBT
CCF501G10000F
CCF501G80600F
750–101–R2.7K
CB3915
CB3325
750–101–R2.7K
750–101–R2.7K
3329H–L58–502
3329H–L58–501
CCF502–C75ROOBT
CCF501G10000F
CCF50–2F237R0F
3329H–L58–502
CCF502–C75ROOBT
CRB20 FXE 11K8
CCF50–2F21000F
CCF501G20001F
CEAE17001B
8.0K
CCF501G20000F
CRB20 FXE 3K57
CCF501G1873FT
CCF501G1873FT
CRB20 FXE 7K15
CCF50G10001F
CRB20T68EFX75R0
CRB20T68EFX75R0
CRB20T68EFX75R0
CRB20T68EFX75R0
8–21
