Tektronix TSG200 Instruction Manual page 100

Replaceable Electrical Parts List (Cont.)
Component Tektronix Serial No.
Number Part Number Effective
A2U605 156–4219–00
A2U606 156–4220–00
A2U607 160–8597–00
136–1038–00
A2U608 156–0956–02
A2U608 156–1920–00 671-1927-03
A2U608 156–0956–02
A2U608 156–1920–00 671-2507-03
A2U609 156–4741–00 671-1927-03
A2U609 156–4741–00 671-2507-03
A2U610 160–8598–00 671-1927-00
A2U610 160–8956–00 671-2507-00
136–0755–00
A2U611 160–8599–00 671-1927-00
A2U611 160–8957–00 671-2507-00
136–0755–00
A2U612 156–2928–00
A2U612 156–1911–00 671-1927-03
A2U612 156–2928–00
A2U612 156–1911–00 671-2507-03
A2U613 156–2928–00
A2U613 156–1911–00 671-1927-03
TSG 200 NTSC Generator Instruction Manual
Serial No.
Discont'd Name & Description
671-2507-01 IC,MEMORY:CMOS,12 LINE X 4 COLUMNS TV
CHARACTER DISPLAY ROM
IC,MEMORY:CMOS,EEPROM,512 X 8,SERIAL,X24C04P,
DIP8.3
IC,DIGITAL:CMOS,PLD,PRGM 156–3825–01,0PT,32
MICROCELL,20NS,83.3MHZ,5032–2,DIP28.3
*MOUNTING PARTS*
SOCKET,DIP:
*END MOUNTING PARTS*
671-1927-02 IC,DIGITAL:LSTTL,BUFFER/DRIVER,DUPLICATE OF
156–0956–00,74LS244,DIP20.3,TUBE
IC,DIGITAL:HCTCMOS,BUFFER,OCTAL,3–STATE,
74HCT244,DIP20.3,TUBE
671-2507-02 IC,DIGITAL:LSTTL,BUFFER/DRIVER,DUPLICATE OF
156–0956–00,74LS244,DIP20.3,TUBE
IC,DIGITAL:HCTCMOS,BUFFER,OCTAL,3–STATE,
74HCT244,DIP20.3,TUBE
IC,LINEAR:BIPOLAR,MISC,ESD/OVERVOLTAGE
PROTECTION SCR ARRAY,14 INPUT,SP720AP,DIP16.3
IC,LINEAR:BIPOLAR,MISC,ESD/OVERVOLTAGE
PROTECTION SCR ARRAY,14 INPUT,SP720AP,DIP16.3
IC,MEMORY:CMOS,EPROM,64K X 8,PRGM
156–3381–00,250NS,27C512,DIP28.6
IC,MEMORY:CMOS,EPROM,64K X 8,PRGM
1563381–00,250NS,27C512,DIP28.6
*MOUNTING PARTS*
SOCKET,DIP:
*END MOUNTING PARTS*
IC,MEMORY:CMOS,EPROM,64K X 8,PRGM
156–3381–00,250NS,27C512,DIP28.6
IC,MEMORY:CMOS,EPROM,64K X 8,PRGM
1563381–00,250NS,27C512,DIP28.6
*MOUNTING PARTS*
SOCKET,DIP:
*END MOUNTING PARTS*
671-1927-02 IC,DIGITAL:ASTTL,FLIP FLOP,HEX D–TYPE,CLEAR,
74AS174,DIP16.3,TUBE
IC,DIGITAL:FTTL,FLIP FLOP,HEX D–TYPE,CLEAR,
74F174,DIP16.3,TUBE
671-2507-02 IC,DIGITAL:ASTTL,FLIP FLOP,HEX D–TYPE,CLEAR,
74AS174,DIP16.3,TUBE
IC,DIGITAL:FTTL,FLIP FLOP,HEX D–TYPE,CLEAR,
74F174,DIP16.3,TUBE
671-1927-02 IC,DIGITAL:ASTTL,FLIP FLOP,HEX D–TYPE,CLEAR,
74AS174,DIP16.3,TUBE
IC,DIGITAL:FTTL,FLIP FLOP,HEX D–TYPE,CLEAR,
74F174,DIP16.3,TUBE
TSG 200 — Replaceable Electrical Parts
Mfr. Code
4T165
60395
TK0198
00779
01295
04713
01295
04713
34371
34371
80009
80009
98291
80009
80009
98291
01295
04713
01295
04713
01295
04713
Mfr. Part Number
UPD6142C001
X24C04P
160859700
2–643543–1
SN74LS244N
MC74HCT244AN
SN74LS244N
MC74HCT244AN
SP720AP
SP720AP
160–8598–00
160–8956–00
DIPS28PIT
160–8599–00
160–8957–00
DIPS28PIT
SN74AS174N
MC74F174N
SN74AS174N
MC74F174N
SN74AS174N
MC74F174N
8–25
