Replaceable Mechanical Parts List
Fig. &
Index
Tektronix Serial No.
Number
Part Number Effective
1–1 200–3898–01
–2 211–0119–00
–3 426–2420–00
–4 211–0119–00
–5 –––– ––––
–6 211–0244–00
–7 129–1411–00
–8 333–3967–00
–9 337–3784–01
–10 211–0244–00
–11 –––– ––––
–12 211–0244–00
–13 211–0025–00
–14 210–0586–00
–15 211–0101–00
–16 337–3750–00
–17 –––– ––––
–18 214–3903–01
–19 –––– ––––
–20 220–0497–00
–21 210–1039–00
–22 –––– ––––
–23 220–0497–00
–24 210–1039–00
–25 348–0844–00
–26 200–3936–00
–26 200–3976–01 B010458
–27 161–0066–00
071–0760–00
TSG 200 NTSC Generator Instruction Manual
Serial No.
Qty Name & Description
Discont'd
1 COVER,TOP:TSG131A
*MOUNTING PARTS*
8 SCREW,MACHINE:4–40 X 0.25,FLH,100 DEG,STL
*END MOUNTING PARTS*
1 FRAME,FRONT:ALUMINUM,ASG100
*MOUNTING PARTS*
2 SCREW,MACHINE:4–40 X 0.25,FLH,100 DEG,STL
*END MOUNTING PARTS*
1 CIRCUIT BD ASSY: FRONT PANEL
(SEE A1 REPL)
*MOUNTING PARTS*
5 SCR,ASSEM WSHR:4–40 X 0.312,PNH,STL
1 SPACER,POST:0.280 X 0.200,ABS
*END MOUNTING PARTS*
1 PANEL,FRONT:TSG200
1 SHIELD,ELEC:ALUMINUM
*MOUNTING PARTS*
2 SCR,ASSEM WSHR:4–40 X 0.312,PNH,STL
*END MOUNTING PARTS*
1 CIRCUIT BD ASSY: MAIN
(SEE A2 REPL)
*MOUNTING PARTS*
8 SCR,ASSEM WSHR:4–40 X 0.312,PNH,STL
2 SCREW,MACHINE:4–40 X 0.375,FLH,100 DEG,STL
2 NUT,PL,ASSEM WA:4–40 X 0.25,STL CD PL
4 SCREW,MACHINE:4–40 X 0.25,FLH,100 DEG,STL
*END MOUNTING PARTS*
1 SHIELD,ELEC:PLASTIC
1 CIRCUIT BD ASSY: REMOTE CONTROL FILTER
(SEE A5 REPL)
*MOUNTING PARTS*
2 SCREW,JACK:4–40 X 0.312 EXT THD,4–40 INT
THD,0.188 HEX,STEEL,CADPLATE
*END MOUNTING PARTS*
1 CIRCUIT BD ASSY: TOP BNC
(SEE A3 REPL)
*MOUNTING PARTS*
2 NUT,PLAIN,HEX:0.5–28 X 0.562 HEX,BRS CD PL
2 WASHER,LOCK:0.521 ID,INT,0.025 THK,SST
*END MOUNTING PARTS*
1 CIRCUIT BD ASSY: BOTTOM BNC
(SEE A4 REPL)
*MOUNTING PARTS*
4 NUT,PLAIN,HEX:0.5–28 X 0.562 HEX,BRS CD PL
4 WASHER,LOCK:0.521 ID,INT,0.025 THK,SST
*END MOUNTING PARTS*
5 PAD,CUSHIONING:0.05 SQ X 0.23
H,POLYURETHANE W/PRESSURE SENS ADHESIVE
B010457 1 COVER,BOTTOM:TSG130
1 COVER,BOTTOM:ALUMINIUM,TSG200,
STANDARD ACCESSORIES
1 CA ASSY,PWR:3,18 AWG,250V/10A,98 INCH
1 MANUAL,TECH:TSG200 INSTRUCTION
TSG 200 — Replaceable Mechanical Parts
Mfr. Code
TK1943
93907
5Y400
93907
01536
TK0588
80009
80009
01536
01536
TK0435
0KB01
93907
TK1155
0KB01
73743
0KB01
73743
0KB01
52152
0J7N4
80009
0B445
80009
Mfr. Part Number
200–3898–01
ORDER BY DESC
426–2420–00
ORDER BY DESC
821–02775
129–1411–00
333–3967–00
337–3784–00
821–02775
821–02775
ORDER BY DESC
ORDER BY DESC
ORDER BY DESC
337–3750–00
214–3903–01
ORDER BY DESC
1224–02–00–0541C
ORDER BY DESC
1224–02–00–0541C
SJ5518–GRAY
200–3936–00
200–3976–01
ECM–161–0066–00
071–0760–00
10–3
