Uplus Lighting 37X15Z User Manual

Wash
Hide thumbs

Advertisement

Quick Links

Download this manual
User manual
37X15Z WASH
Please read the instructions carefully before use

Advertisement

loading
Need help?

Need help?

Do you have a question about the 37X15Z and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting 37X15Z

Summary of Contents for Uplus Lighting 37X15Z

  • Page 1 User manual 37X15Z WASH Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………4-5 DMX Channels ……………………………………………………………………………………6-12 Trouble Shooting…………………………………………………………………………………12 Fixture Cleaning………………………………………………………… ………………………13 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...

  • Page 4: Technical Specifications

    fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals.
  • Page 5 Slow Fast Sound Manual Yes/No Invert Tilt Yes/No Invert word Yes/No English/Chinese Display Set LCD Backlight on 000 - 255 Panmico 000 - 255 Pan fining adjust Tilt 000 - 255 TiltMICO 000 - 255 Tilt fining adjust ZOOM 000 - 255 000 - 255 Manual Set STROBE...

  • Page 6: Dmx Channels

    DMX Channels 48 CH Mode Function DMX value Description 0-255 0~540 adjust Pan fine 0-255 16bit adjust Tilt 0-255 0~270 Tilt fine 0-255 16bit 可调 Speed of pan/tilt 0-255 From fast to slow Zoom 0-255 Zoom from small to big Dimming 0-255 0-100% dark to bright...
  • Page 7 50-59 Effect 5 60-69 Effect 6 70-79 Effect 7 80-89 Effect 8 90-99 Effect 9 100-109 Effect 10 110-119 Effect 11 120-129 Effect 12 130-139 Effect 13 140-149 Effect 14 150-159 Effect 15 160-169 Effect 16 170-179 Effect 17 180-189 Effect 18 190-199 Effect 19...
  • Page 8 Back light G 0-255 0~255 control(39CH,40CH)back light Back light B 0-255 0~255 control(39CH,40CH)back light Back light W 0-255 0~255 control(39CH,40CH)back light 0-127 Dynamic pattern Positive direction Adjust effect direction 128-255 Dynamic pattern opposite direction Effect speed 0-255 from fast to slow No function Priority 1:Marco 10-99...
  • Page 9 LED4 G Dimming 0-255 Zone 4 G dimming from dark to bright LED4 B Dimming 0-255 Zone 4 B dimming from dark to bright LED4 W Dimming 0-255 Zone 4 W dimming from dark to bright No function Priority 5:CTO 10-255 10000K-2500K No function...
  • Page 10 170-179 Effect 17 180-189 Effect 18 190-199 Effect 19 200-209 Effect 20 210-255 Static pattern effect (build-in effect) No function Priority 2: dynamic Per 12 DMX value one effect, total 20 types effect 10-255 effect Back light R 0-255 0~255 control(27CH,28CH)back light Back light G 0-255 0~255 control(27CH,28CH)back light...
  • Page 11 No function 10-19 Effect 1 20-29 Effect 2 30-39 Effect 3 40-49 Effect 4 50-59 Effect 5 60-69 Effect 6 70-79 Effect 7 80-89 Effect 8 90-99 Effect 9 100-109 Effect 10 Priority 4: Build 110-119 Effect 11 in color effect 120-129 Effect 12 130-139...

  • Page 12: Trouble Shooting

    No function Priority 2: dynamic Per 12 DMX value one effect, total 20 types effect 10-255 effect Back light R 0-255 0~255 control(15CH,16CH)back light Back light G 0-255 0~255 control(15CH,16CH)back light Back light B 0-255 0~255 control(15CH,16CH)back light Back light W 0-255 0~255 control(15CH,16CH)back light 0-127...

  • Page 13: Fixture Cleaning

    7.Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Clean with soft cloth using normal glass cleaning fluid.
