Summary of Contents for Uplus Lighting 7X40 B EYE
- Page 1 User manual 7X40 B EYE Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………………3 Technical Specifications……………………………………………………………………………4 Control Menu ………………………………………………………………………………………5-6 DMX Channels …………………………………………………………………………………7-11 Dimension ……………………………………………………………………………………12 Lumen data ……………………………………………………………………………………12 Trouble Shooting……………………………………………………………………………………13 Fixture Cleaning………………………………………………………… …………………………13 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Input Voltage: 100-240V, 50/60Hz Power consumption: 300W Power supply: 350W Single LED power: 40W Light source: 7x40W RGBW 4IN LED Beam angle: 4-60° Adjustable color temperature DMX Channel: 23/35/51CH Operate mode: DMX512, AUTO master/slave, Voice control，RDM Electronic dimmer:0～100% linear Linear CTO color temperature adjustment: 2500-8000K Three phase silent motor fast and stable Fast operation speed and noiseless operation... -
Page 5: Control Menu
3.Control Menu First interface Description Explain Button up and down: Change the address code of this light, for example, if the channel value is 23CH, then the address code of this light is 1, and the Address 001 - 512 address code of the next light is 24;... - Page 6 Encoder Correct on/off Hall correct ON/OFF Back lighting time 15s/30s/LOGO/OFF Curve1/Curve2/ Curve Curve3/Curve4 Load default OK/Cancel Adjust Enter password xxxx Current channel mode TEST 0-255 Channel Motor ON/OFF Reset Head Reset Reset XY Reset ALL Error message Display specific information content DMX data Display specific testing content for DMX Info...
-
Page 7: Dmx Channels
4.DMX Channels 23CH Function DMX value Description 0-255 X rotate X fine 0-255 X-axis fine adjustment 0-255 Y rotate Y fine 0-255 Y-axis fine adjustment XY speed 0-255 Fast-slow zoom 0-255 Angle From large to small 0-127 0-60 degree 128-188 Antiwise fast-slow rotating 189-193... - Page 8 Background Dark-bright 0-255 Background Dark-bright 0-255 Background Dark-bright 0-255 No function 0-79 Curve 1 (5s) 80-99 Curve 2 (5s) 100-119 Curve 3 (5s) 120-139 Curve 4 (5s) 140-159 reset Slow dimming mode (5s) 160-179 Fast dimming mode (5s) 180-199 Effect motor reset (5s) 200-209 XY motor reset (5s) 210-219...
- Page 9 Dimmer Fine 0-255 Dimmer fine 0-255 0-255 Pan fine X fine 0-255 tilt 0-255 Tilt fine Y fine function 0-255 reserve No function 0-79 Curve 1 (5s) 80-99 Curve 2 (5s) 100-119 Curve 3 (5s) 120-139 Curve 4 (5s) 140-159 reset Slow dimming mode (5s) 160-179...
- Page 10 adjustment Prospect 0-255 Prospect strobe（with 11 chs） strobe Background 0-255 Background strobe（with 11 chs） strobe Background 0-255 Background selection selection 51CH Function DMX value description 0-255 Pan fine X fine 0-255 tilt 0-255 Tilt fine Y fine 0-255 XY speed 0-255 Fast-slow zoom...
- Page 11 Forward fast-slow 0-127 Dynamic effect speed Reverse slow-fast 128-255 Dark-bright Background R 0-255 Dark-bright Background G 0-255 Dark-bright Background B 0-255 Dark-bright Background W 0-255 No function 0-79 Curve 1 (5s) 80-99 Curve 2 (5s) 100-119 Curve 3 (5s) 120-139 Curve 4 (5s) 140-159 reset...
-
Page 12: Dimension
5.Dimension 6.Lumen data... -
Page 13: Trouble Shooting
7.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
