Summary of Contents for Uplus Lighting 7X45 COB PAR
- Page 1 User manual 7X45 COB PAR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 2. Technical Specifications………………………………………………………………………4 3. Control Menu ……………………………………………………………………………………4-5 4. DMX Channels ……………………………………………………………………………………6-8 5. Trouble Shooting…………………………………………………………………………………9 6. Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Light Sources: 7*45W COB 3in1 LED Power Consumption: 320W Power Voltage: AC 100-240V, 50/60Hz Beam angle:12°/36° Dimension:230*290*90mm; NW:3.6 KGS Control DMX Channel: 3/7/25 Channel Control Modes: DMX 512, Auto mode, Master/Slave, Sound active Construction Display: Digital panel Data In/Out socket: 3-pin XLR sockets Protection Rating: IP20 Features Good cooling system, over heat protection... - Page 5 Display: [A] menu selection or return to previous menu. [B] press [B] through the menu list to increase/change the value of the current function. [C] press [C] through the menu list to decrease/change the value of the current function. [D] confirm & quit out current function setting. Display panel operation instructionDisplay panel operation instruction Show Function...
-
Page 6: Dmx Channels
4.DMX Channels DMX channel´ s functions and values (25 DMX channels): Channel Function DMX Value Instruction Total Dimmer 0~255 Total Dimmer- Dark to Bright Total strobe 0~255 Total Strobe-slow to fast No function 6~11 Build in effect 1 12~17 Build in effect 2 18~23 Build in effect 3 24~29... - Page 7 186~191 Build in effect 31 192~197 Build in effect 32 198~203 Build in effect 33 Build in effect 204~209 Build in effect 34 210~215 Build in effect 35 216~250 Gradient 251~255 Sound control speed 0~255 Fast to slow 0~255 R1 Dimmer Red1 Dimmer- Dark to Bright 0~255 G1 Dimmer...
- Page 8 48~53 Build in effect 8 54~59 Build in effect 9 60~65 Build in effect 10 66~71 Build in effect 11 Build in effect 72~77 Build in effect 12 78~83 Build in effect 13 84~89 Build in effect 14 90~95 Build in effect 15 96~101 Build in effect 16 102~107...
-
Page 9: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
