- Page 1 User manual 150 SPOT Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 2. Technical Specifications…………………………………………………………………………4 3. Control Menu ……………………………………………………………………………………5-7 4. DMX Channels ……………………………………………………………………………………8-9 5. Dimension …………………………………………………………………………………………10 6. LUX DATA …………………………………………………………………………………………10 7. Trouble Shooting…………………………………………………………………………………11 8. Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. • Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. -
Page 5: Control Menu
8. Housing material: PA6 Nylon( Solid,high temperature resistance up to 200°flame retardance) 3.Control Menu Up and down keys to select edit Confirm key: execute function, start editing, exit editing menu key: return to the previous interface The following takes "Modify DMX Address Code" as an example to describe the use of buttons: 1. - Page 6 set up Option Description operating mode Slave state: receive DMX signal from console or host AUTO Master status: self-propelled and send DMX signal to slave voice control DMX address 1~512 Press the "OK" key to enter the editing state. At this time, the hundreds digit is selected, and the "up"...
- Page 7 enlarge reset Factory Sensor detection X Hall Y Hall color hall Pattern Hall glass pattern hall Focus Hall X-coded step value Y-coded step value reset calibration X axis After entering the sub-interface, you can adjust the reset position of the X-axis, Y-axis and other motors to make up for the error in the hardware Y axis installation.
-
Page 8: Dmx Channels
failed Focus reset failed Focusing Hall, or there is a problem with the focusing motor 4.DMX Channels CH17 Function CH Value Effect 000-255 Horizontal 540 degree scan X fine 000-255 Horizontal 1.2 degree fine-tuning 000-255 Vertical 270 degree scan Y fine 000-255 Vertical 1.2 degree fine-tuning XY speed... - Page 9 056 - 063 Static Gobo8 064 - 071 Static Gobo1shock (from slow to fast) 072 - 079 Static Gobo2shock (from slow to fast) 080 - 087 Static Gobo3shock (from slow to fast) 088 - 095 Static Gobo4shock (from slow to fast) 096 - 103 Static Gobo5shock (from slow to fast) 104 - 111...
-
Page 10: Dimension
5.Dimension 6.LUX DATA... -
Page 11: Trouble Shooting
7.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2. -
Page 12: Fixture Cleaning
8.Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics .
