- Page 1 User manual LED PROFILE AZ Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 2. Technical Specifications………………………………………………………………………4 3. Unpacking…………………………………………………………………………………………5 4. Control Menu ……………………………………………………………………………………6 5. DMX Channels ……………………………………………………………………………………7 6. Dimension …………………………………………………………………………………………8 7. Trouble Shooting…………………………………………………………………………………9 8. Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Feature： 1*200W COB LED (available for RGBW 4in1) 50,000 hours life time and low power consumption Color Rendering Index(CRI): Ra≥90 High quality optical system and field uniformity High contrast aspheric lens Auto zoom system(Motorized zoom) from 15°-38° Beam edge continually adjustable hard-to-soft Aluminum alloy housing Thermally insulated rear handle High-strength single handle design... -
Page 5: Unpacking
Meanwhile, please keep this manual well for future needs. The LED PROFILE AZ is made of a high strength of aluminum alloy casing with nice outlook. The fixture is designed and manufactured strictly following CE standards, complying with international standard DMX512 protocol. -
Page 6: Control Menu
4.Control Menu MENU key: Change to the main menu (no more details in below sheet). UP/DOWN key: Change the value of the current menu (see below sheet for details). ENTER key: If there is a submenu, change the submenu (see below sheet for details). Menu Vice Menu Display... -
Page 7: Dmx Channels
5.DMX Channels Model – CH12 Channel Data Function Notes 0~255 Dimmer 0~255 Color 1 (red) 0~255 Color 2 (green) 0~255 Color 3 (blue) 0~255 Color 4 (white) 0~30 No effect 31~200 Multi-color change 201~205 Color temperature 1 (default 3200K) …… Color temperature 2~10（each 5 data is a color temperature）... -
Page 8: Dimension
6.Dimension Size of the fixture: 195(D)*720(W)*415(H)mm... -
Page 9: Trouble Shooting
8.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
