- Page 1 User manual (Auto zoom 15-50°) 300 AZ-SPOT PR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 2. Technical Specifications………………………………………………………………………4 3. Descriptions………………………………………………………………………………………5 4. Unpacking…………………………………………………………………………………………5 5. Control Menu ……………………………………………………………………………………6-7 6. DMX Channels ……………………………………………………………………………………8 7. Dimension …………………………………………………………………………………………9 8. LUX Date ……………………………………………………………………………………………9 9. Trouble Shooting…………………………………………………………………………………10 10. Fixture Cleaning………………………………………………………… ………………………10 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Light Source: LED POWER: 300W Cool White 5600K or Warm White 3200K (200W) COB LED Led Lamp: Imported LED Color Rendering Index(CRI): Ra≥90 LED Life Time: over 50,000 hours Power supply: Voltage: AC100-240V Max.power: 300W Optics: Zooming Scale: 15-50° DMX auto zoom optional Soft and even field of light Features:... -
Page 5: Descriptions
3.Descriptions · ·Works perfectly on conventional dimmers or constant power with DMX ·Motorized zoom angle between 15° to 50°, manually ·Ultra smooth 16-bit dimming of master dimmer ·Soft and even field of light ·Simple and complex DMX channel profiles for programming versatility ·Warm white and cool white Fresnel-style lighting fixture ·Virtually silent operation for use in studio and theatre applications 4.Unpacking... -
Page 6: Control Menu
5.Control Menu Menu Data Menu State Operative Mode DMX address DMX channel Mode Speed of Dimmer No DMX signal Screen Savers Main Menu Vice Menu Screen Rotation Language switching Speed of Dimmer Manual mode System information Reset Restore the default settings Key Operation Vice Menu State... - Page 7 Manual mode Press “ENTER” to Manual mode, Not receive control signals System Press “ENTER” to ensure，View the version number and the elapsed time information Press “ENTER”to confirmation dialog box, then press”ENTER” again to Reset Ensure/Cancel reset motor. Press "Cancel" to exit the dialog box. Restore Press “ENTER”to confirmation dialog box, then press”ENTER”...
-
Page 8: Dmx Channels
6.DMX Channels Model – CH5 Channel Data Function Mark 0~255 dimmer 0-255 linear dimmer speed of dimmer speed of dimmer 2 Default 10~29 Turn off speed of dimmer 30~69 speed of dimmer 1 speed of dimmer 4 (the slowest and 70~129 speed of dimmer 2 softest) -
Page 9: Dimension
7.Dimension Size of the fixture: 379 (D)*211(W)*378(H)mm 8.LUX Date... -
Page 10: Trouble Shooting
9.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
