Kimball Office Aspire Assembly Instructions

Aspire ®
1-Piece Static Table Top
Replacement
Tools Required
Phillips Screwdriver
Package Contents
1-Piece Replacement Top
Installation
Note: This instruction explains basic installation of Aspire
1-piece static replacement tops.
Caution: There are factory-installed locating screws inserted
on the underside of the replacement top at each end. The
locating screws aid in the correct positioning of the top on
the table frame. Driving the locating screws all the way in
WILL CAUSE DAMAGE to the topside worksurface. The
manufacturer is not responsible for any damage caused by
driving the locating screws in. (See Figure C for example of
locating screw position).
1. Make sure table is in upright position on a level, solid
surface. (Figure A).
2. Remove the table top from the frame. Older model table
tops are attached to the frame with screws. Newer model
table tops are attached to the frame with clamps. On older
model tops, remove all screws holding the top to the frame.
Discard screws and remove top from frame. On newer
model tops, release all clamps holding top to frame by
pulling downward on each clamp lever. Lift top straight up
to remove. (Figure B).
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Care.
Part No. 1741584 Revision B-04
Electric Screw Gun with
Phillips Bit
Worksurface Clamps
Tables Assembly Instructions
Figure A
Table must be in upright position
Figure B
Page 1 of 2
Release all clamps on
newer table tops. Pull
downward on clamp lever.
Remove screws on
older table tops
