Kimball Office Aspire Assembly Instructions

Aspire ®
Unfold 4-Piece Folding Tables

Tools Required

Utility Knife

Package Contents

4-piece Folding Table

Installation

1. Position folded table in desired location. Cut all plastic ties
from table frame, springs, and undersurface cabling.
(Figure A).
2. To unfold table, open only one section of the table at a time.
Pull outward on the outer section at one end of the table.
Push down on the middle areas of the worksurfaces. Be
careful to keep hands away from pinch points. (Figure B).
Note: If both sections of the table are folded/unfolded at
the same time, the worksurfaces will be damaged.
3. Table section will stop unfolding when worksurface pieces
are horizontal. (Figure C).
4. To lock table section in position, firmly pull locking handles
out and turn handle ends away from each other so that the
handles are parallel to the bottom side of the worksurface.
Release handles to allow them to snap into the locked
position. (Figure D).
Note: Locking handles are on both sides of the table. Make
sure all handles are in the locked position before using table.
Figure C
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Care.
Part No. 1699156 Revision C-03
#3 Allen Wrench
Tables Assembly Instructions
Figure A
Cut plastic
ties from
cables and
springs
Cut plastic
ties from
frame
Figure B
Figure D
Page 1 of 2
Pull out
Lock
