Kimball Office Aspire Assembly Instructions

Aspire ®
Mount Wood Top To
Table Base Understructure

Tools Required

#4 Hex Driver
Utility Knife

Package Contents

1 Understructure
2 Worksurface Half

Installation

Note: These instructions provide basic information for
installing wood tops to the base understructure. For safety
purposes and to avoid damage and/or injury, it is
recommended that the wood tops be installed with the base
in the upright position.
1. Make sure understructure is in upright position. Unpack
casters and insert one in each leg. The casters screw in and
can be tightened using the adjustable wrench. (Figure A).
2. Remove all plastic ties securing the folded frame. (Figure B).
3. Unfold frame by pulling outward on outermost legs.
(Figure C).
Figure C
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Care.
Part No. 1741646 Revision C-05
Adjustable Wrench
#3 Allen Wrench
6 Glides or Casters
48 M6 X 16MM Screws
Tables Assembly Instructions
Figure A
Page 1 of 3
Figure B
Remove
all
plastic
ties
Remove
all
plastic
ties
