13 Information on scattered
US
radiation
13.1

CBCT scattered radiation

Test equipment: Dosimeter Radcal 9015
Test conditions
Program parameters
Image acquisition vol-
ume
Voltage
Current
R 1 m
° mR/h
0 588.2
45 549.3
90 472.6
135 458.8
180 12.9
225 410.5
270 663.2
315 429.7
13.2

Pano scattered radiation

Test equipment: Dosimeter Radcal 9015
Test conditions
Program parameters
Patient size
Voltage
Current
R 1 m
° mR/h
0 60.9
45 19.6
90 10.6
135 22.1
180 1
225 45.4
270 47.6
52
CBCT
Normal
99 kVp
14 mA
1.5 m 2 m
mR/h mR/h
135.3 87.1
249.4 106.8
307.3 78.4
287.6 89.3
4.6 1.3
288.7 98.2
301.4 112.4
194.2 92.3
Panoramic Standard
Normal
80 kVp
14 mA
1.5 m 2 m
mR/h mR/h
17.7 8
12.4 5.8
6.8 4.1
12.5 5.6
0 0
21.4 9.4
21.9 9.2
R 1 m 1.5 m
° mR/h mR/h
315 76.4 19.4
2210200496L41 1911V006
2 m
mR/h
8.6
