Product description
EN-
5.5
Exposure button
US
Exposure switch
The exposure switch is used to trigger the pre-
pared image acquisition and start the X-ray expo-
sure. The LED indicates the status of the unit, as
does the LED on the unit.
– Green: unit ready for recording
– Yellow: X-ray beam active
1
Indicator lamp (LED)
2
Exposure button
5.6
Memory card slot
The unit has a slot for a memory card. The slot is
needed for service purposes only.
20
5.7
The active sensor surface is indicated by the
markers in the corners of the sensor window.
The cross indicates the geometric mid-point of
the active sensor surface.
1
2
1
2
Sensor window
Active sensor surface
Geometric mid-point of the active sensor
surface
2210200496L41 1911V006
1
2
