Image acquisition programs
CBCT images
CBCT
The CBCT image shows the jaw area.
The size of the jaw area shown depends on the selected image volume.
Resolution: 200 μm
CBCT 5x5 Maxilla Molar right
The X-ray image depicts the right molar region of the maxilla with a volume of
5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Maxilla Premolar right
The X-ray image depicts the right premolar region of the maxilla with a volume of
5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Maxilla Front
The X-ray image depicts the front region of the maxilla with a volume of 5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Maxilla Premolar left
The X-ray image depicts the left premolar region of the maxilla with a volume of
5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Maxilla Molar left
The X-ray image depicts the left molar region of the maxilla with a volume of 5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Mandible Molar right
The X-ray image depicts the right molar region of the mandible with a volume of
5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Mandible Premolar right
The X-ray image depicts the right premolar region of the mandible with a volume of
5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Mandible Front
The X-ray image depicts the front region of the mandible with a volume of 5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Mandible Premolar left
The X-ray image depicts the left premolar region of the mandible with a volume of
5x5 cm.
Resolution*: 120 μm
CBCT 5x5 Mandible Molar left
The X-ray image depicts the left molar region of the mandible with a volume of
5x5 cm.
Resolution*: 120 μm
* The resolution can be changed to 80 μm in the service menu of the unit.
For panoramic images of children, the size of the radiation field is reduced with the aid of an additional
collimator. The radiation dose is significantly reduced for this image.
