Usage
EN-
Inserting the positioning aid for panoramic
US images with hygienic protective cover (optional)
WARNING
Risk of cross contamination due to
non-reprocessed bite block
Reprocess the bite block in accord-
❯
ance with the reprocessing instruc-
tions.
Optionally place a hygienic protective cover
❯
over the bite block.
32
Inserting the positioning aid for the maxillary
joint image
Correct image acquisition is only possible with
the chin support for maxillary joint images.
Inserting the chin support for the maxillary joint
❯
image.
Inserting the positioning aid for sinus images
Inserting the chin support for sinus images.
❯
