Technical Specifications; Warranty Information - NTI Enviromux Series Installation And Operation Manual

NTI ENVIROMUX Low Cost Carbon Dioxide Sensor

TECHNICAL SPECIFICATIONS

Detection Range
Accuracy
Stability
Non-linearity
Response time
Data update time
System warm-up time
Power
Current Draw
Output Signal
Operating Temperature
Operating Relative
Humidity
Enclosure Material
Size WxDxH
Approvals
Note: This sensor will provide indication of the presence of carbon dioxide to an ENVIROMUX Enterprise
Environment Monitoring System (E-16D/-5D/-2D) when connected through an E-S5VDC sensor converter.

WARRANTY INFORMATION

The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network
Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at
information regarding repairs and/or returns. A return authorization number is required for all repairs/returns.
0-5000 ppm
±50ppm+3% Full scale) at 25℃
<2%F-S
<1%F-S
90% step change is generally less than 90S
2s
2 minutes (ready to function/; 10 minutes (maximum accuracy)
10 to 30VDC (110-240VAC, 50 or 60Hz-12VDC/1A AC Adapter supplied)
60mA (@12VDC)
0-5VDC
-10˚ to 50˚C
0 to 80% RH non-condensing
ABS Plastic, IP65
4.33x1.73x3.35 in. (110x44x85mm)
CE
3
for
http://www.networktechinc.com
MAN426 Rev. 10/04/22
