www.ti.com
7.3 Layout
Figure 7-4
shows a consolidated layout overview. As a legend, the top layer is shown in red, the top overlay in
yellow, and the bottom layer in blue.
SBAU409 – SEPTEMBER 2022
Submit Document Feedback
Figure 7-4. ADS9218EVM Layout
Copyright © 2022 Texas Instruments Incorporated
Bill of Materials, Schematics, and Layout
ADS9218EVM-PDK Evaluation Module
23
