5.7.10 Reset
When PWR LED starts flashing on the front panel, it is possible to restore the default con-
figuration of the router by pressing the RST button on the front panel. After pressing this button
the default configuration is restored and then router reboots (green LED will be on).
For pressing the RST button could be used a narrow screwdriver.
We recommend backing up configuration of the router (see Configuration manual for v2
routers) because reset of the router sets the configuration to the default state.
It is important to distinguish between reset and reboot the router.
Action Router behavior
Reboot Turn off and then turn on router
Reset Restore default configuration and reboot
the router
Table 11: Description of reset and restart router
Figure 35: Router reset
Invoking events
Disconnect and connect the power,
Press the Reboot button in the web
configuration
Press RST button
