5. Router Design

5.1 Router versions

ER75i v2 router is supplied in the following versions (see table below). All versions are
available in plastic or metal box according to customer requirements.
Router versions
ER75i v2B
ER75i v2B SL
ER75i v2F
ER75i v2F SL
Figure 2: Front panel ER75i v2B
Figure 3: Front panel ER75i v2F
Figure 4: Front panel ER75i v2F with WiFi
Router Box
Plastic 1 x
Metal 1 x
Plastic 1 x
Metal 1 x
Table 1: Router versions
Figure 5: Front panel ER75i v2B SL
Figure 6: Front panel ER75i v2F SL
Figure 7: Front panel ER75i v2F SL with WiFi
6
5. ROUTER DESIGN
1 x 1 x 1 x
1 x 1 x 1 x
1 x 1 x 1 x 1 x 1 x
1 x 1 x 1 x 1 x 1 x
1 x
1 x
1 x
1 x
