Wine Guardian D200 Installation, Operation And Maintenance Manual page 54

图 1
图 2
图 3
48
1. Disconnect the controller wire from the side of the
Wine Guardian unit and save for future use.
1. 断开酒卫装置侧面的控制器电线，以备后续使用。
2. Plan on mounting the remote interface controller on
a solid surface away from doors, corners, air outlets,
drafts or heat generating equipment. Do not mount
the remote interface controller directly on an outside
wall, a wall adjacent to a boiler room, or other hot
area. Use a piece of foam insulation behind the
sensor to insulate it from a hot or cold surface. The
recommended height is four to five feet above the
finished floor.
请计划将远程接口控制器安装在远离门、角、出风
2.
口、通风或发热设备的固体表面上。请勿将远程接口控
制器直接安装在外墙、邻近锅炉房的墙壁或其他高温区
域内。请在传感器后面使用一块泡沫绝缘材料将其与热
表面或冷表面隔离。建议高度为竣工地面以上 4 至 5 英
尺。
3. Unscrew and remove the back plate from the
Remote Interface Controller (Fig. 1)
3. 从远程接口控制器上拆下并移除背板（图 1）
4. Place the back plate against the wall and mark the
mounting points at the desired location. (Fig. 2)
4. 将背板靠墙放置，并在所需位置标记安装点。（图
2）
5. Drill two one-eighth inch holes and insert anchors within
the mounting surface. Anchors may not be required if
securing to a wall stud or racking system. Insert the
screws into the holes and test fit the backing plate for
mounting to ensure it mounts easily onto the two screws
and slides down onto the slotted openings freely (Fig. 3)
5. 在安装面上钻两个八分之一英寸的孔并插入锚。如果
是固定在墙柱或支架系统上，可能不需要锚。将螺钉插
入孔中，并测试安装背板，以确保其可以很容易安装到
两个螺钉上，并可顺利滑入开槽开口（图 3）。
