Connector details

Key information about the connections of the EVAL-M1-101TF evaluation board is described below.
Table 5 provides the pin assignments of the iMOTION™ MADK-M1 20-pins interface connector J1. This connector
is the interface to the power board.
Table 5 J1- iMOTION™ MADK-M1 20 pin- interface connector for control board
Pin No. Pin
1 PWMUH
2 GND
3 PWMUL
4 GND
5 PWMVH
6 +3.3V
7 PWMVL
8 +3.3V
9 PWMWH
10 IU+
11 PWMWL
12 IU-
13 GK
14 DCBSENSE
15 VTH
16 IV+
17 IV-
18 IW+
19 IW-
20 VCC
J2 is the interface to iMOTION Link, the MCE debugger cable, for downloading code and parameter. Please be
noted, normally user use the on-board debugger other than an additional iMOTION Link. J4 is an interface for
some special mode speed reference requirement, especially for fan application.
Table 6 J2- iMOTION Link
Pin Name
1 TXD1
2 RXD1
3 VDD
4 GND
5 GND
6 VDD
7 RXD0
8 TXD0
User guide
Details
3.3 V compatible logic output for high side gate driver-Phase U
Ground
3.3 V compatible logic output for low side gate driver-Phase U
Ground
3.3 V compatible logic output for high side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic output for low side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic output for high side gate driver-Phase W
Shunt voltage phase U
3.3 V compatible logic output for low side gate driver-Phase W
Ground
Gatekill signal – active low when overcurrent is detected
DC bus positive voltage, scaled in 0-3.3 V range by a voltage divider
Thermistor input
Shunt voltage phase V
Ground
Shunt voltage phase W
Ground
Defined for 15 V power supply (not used in this board)
Pin name connector
User serial debug clock for MCU
User serial debug I/O for MCU
+3.3 V power supply
Ground
Ground
+3.3 V power supply
Reception of UART0 for MCE
Transmission of UART0 for MCE
