EVAL-M1-101TF user guide
iMOTION™ Modular Application Design Kit
System and functional description
Table 3 MCEWizard setup overview table
Parameter
Power board selecting
Motor 1 shunt configuration
Controller supply voltage
Max DC bus voltage
DC bus sensing high resistor
DC bus sensing low resistor
NTC temperature shutdown
value
GateSense low-side devices
GateSense high-side devices
Motor 1 Current input
To start the MCEWizard system setup procedure, click the "Next" button in the right bottom corner as shown in
Figure 6.
Figure 6 Opening the default configuration file of this board
After all the MCEWizard questions are answered, the "Verify & Save Page" will be shown as in Figure 7.
User guide
Value
MADK power board name
Refer to the power board App Note
Refer to the power board App Note
Refer to the power board App Note
Refer to the power board App Note
13.3 kOhm
Calculated as in Section 2.5.2
Refer to the power board App Note
Refer to the power board App Note
Calculated as the Section 2.4.2
11 of 32
Comment
If no, select similar
power board to modify
VDD is 3.3 V by default
Refer to the power
board App Note
High is true by default
High is true by default
V. 1.0
2020-11-03
