EVAL-M1-IM241 user guide
iMOTION™ modular application design kit
System design
S. No. Ref Designator
4 CX1, CX2
5 CY3, CY4
6 C1, C13
7 L2
3.4

Connector details

General information about the connectors of the EVAL-M1-IM241 reference design is provided in this section.
Table 4 includes the details of the AC input connector.
Table 4 AC input connector (X1)
Pin Label
1 E
2 N
3 L
Table 5 provides the details of the motor UVW output connector X2.
Table 5 Motor side connector (X2)
Pin Label
1 U
2 V
3 W
Table 6 provides the pin assignments of the 20-pin iMOTION™ MADK-M1 interface connector X3. This connector
is the interface to the controller board.
Table 6 X3 - iMOTION™ MADK-M1 20-pin interface connector for controller board
Pin Name
1 PWMUH
2 GND
3 PWMUL
4 GND
5 PWMVH
6 +3.3 V
7 PWMVL
User guide
Description
CAP FILM 470 nF 630 V
10% MKP (Metallized
Polypropylene)
CAP CSSA Multilayer
Ceramic Chip Safety
Capacitor X1/Y2 470
pF 250 VAC
CAP ELCO 150 uF 400
V 20%
Aluminiumelectrolytic
Common choke
Function
Connected to motor phase U
Connected to motor phase V
Connected to motor phase W
Pin name connectors
3.3 V compatible logic input for high side gate driver-Phase U
Ground
3.3 V compatible logic input for low side gate driver-Phase U
GND ground
3.3 V compatible logic input for high side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic input for low side gate driver-Phase V
25 of 38
Manufacturer Manufacturer P/N
Wurth Elektronik 890324025039CS
Wurth Elektronik 8853522110011
Wurth Elektronik 860021381022
Yunlu Energy
0324510376A
Technology
Function
Earth ground
AC neutral input
AC line input
V0.1
2021-03-19
