ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Reference Designator
C1 to C3, C7, C27, C28, C30 to
C32, C34, C45, C67
C10
C11, C21, C66
C12, C13, C19, C23, C24, C35, C36
C5, C14 to C16, C18
C17
C20, C26, C40, C41
C22
C9, C25
C29
C33
C6, C39
C43, C44, C65, C68
C63, C64
C8
CE, CLK, DATA, GND1, GND2, LE,
MUXOUT, PDBRF, SCL, SDA,
VSUPPLY
CN1
DS1
GND
L1, L2
L5, L8
R1
R3, R4, R7, R11, R16, R23 to R27,
R32, R35, RMUX, RMUXOUT
R12 to R14
R17
R2, R8
R20
R22
R33
R34
R5, R9
R6
R10, R15
RCLK, RDATA, RLE
RE1, RE2
Description
Ceramic capacitor, X7R
Ceramic capacitor, NPO
Ceramic capacitor, X7R
Ceramic capacitor, COG (NPO),
general-purpose
Ceramic capacitor, multilayer, X5R
Ceramic capacitor, X5R
Ceramic capacitor, X5R, general-
purpose
Ceramic capcitor, NPO
Ceramic capacitor, X5R, general-
purpose
Ceramic capacitor, COG (NPO),
general-purpose
Ceramic capacitor, X7R
Ceramic chip capacitor, 10 pF RF
Ceramic capacitor, COG (NPO),
general-purpose
Ceramic capacitor, X7R, general-
purpose
Ceramic capacitor, multilayer, X7R
PCB connectors, test point yellow
(TP-104-01-04-YE)
PCB connector, board-to-board
receptacle, 0.6 mm pitch
LED, SMD (green)
PCB connector, single socket, black
Inductor chip
Inductor chip
Precision resistor, thick film chip
Resistor, thick film chip
Precision resistor, thick film chip
Precision resistor, thick film chip
Resistor, general-purpose film
Resistor, thick film chip, 0603
Resistor, thick film chip, 0603, 1%
Resistor, thick film, SMD, 0603, 1%
Precision resistor, thick film, chip,
R0603
Resistor, thick film
Resistor, film, SMD, 0402
Do not install
Precision resistor, thick film, chip
Precision resistor, thick film, chip
Rev. A | Page 12 of 13
EV-ADF4356SD1Z User Guide
Value Manufacturer
0.1 μF Kemet
100 pF PHYCOMP (Yageo)
1 μF AVX Corporation
1000 pF Murata
10 μF TDK
10 μF TDK
0.1 μF Murata
120 pF PHYCOMP (Yageo)
1 μF Murata
2700 pF Murata
22 pF AVX Corporation
10 pF AVX Corporation
120 pF Murata
100 pF Murata
4.7 μF Taiyo Yuden
N/A Components
1
Corporation
N/A 1 Hirose Electrical
N/A Broadcom Limited
1
N/A Deltron
1
7.4 nH Coilcraft
100 nH Coilcraft
75 kΩ Panasonic
0 Ω MULTICOMP
1.8 kΩ Panasonic
10 kΩ Panasonic
1 Ω Yageo
500 Ω Vishay Precision
Group
1.5 kΩ MULTICOMP
2.7 kΩ MULTICOMP
10 kΩ Panasonic
0.1 Ω Panasonic
100 Ω Venkel
50 Ω Vishay Thin Film
1.5 kΩ Panasonic
100 kΩ Panasonic
Product No.
C0402C104K4RACTU
2238 867 15101
0603YC105KAT2A
GRM1555C1H102JA01
C2012X5R1E106K085AC
C1608X5R1A106M080AC
GRM155R61A104KA01D
CC0603JRNP09BN121
GRM155R60J105KE19D
GRM188C1H272JA01D
06035C220JAT2A
0201ZK100GBSTR
GRM1555C1H121JA01
GRM033R71E101KA01D
LMK212B7475KG-T
TP-104-01-04
FX8-1205-5V(21)
HSMG-C170
571-0100
0302CS-7N4XJLU
0402CS-R10XJLU
ERJ-2RKF7502X
MC00625W040210R
ERJ-2RKF1801X
ERJ-2RKF1002X
RC0603FR-071RL
CRCW0603500RFKEA
MC0063W060311K5
MC0063W060312K7
ERJ-3EKF1002V
ERJ-2BSFR10X
CR0402-16W-1000FPT
FC0402E50R0FST1
ERJ-6ENF1501V
ERJ-6ENF1003V
