System Name Article #
BPS-i600.1 100-91405
BPS-i600.2 100-91406
Pos. Component Article Name
1 Pump Head LPP-600.29
Integrated
2a IPD-600.1-50-01
Pump Driver
Integrated
2b IPD-600.2-50-01
Pump Driver
Pos. Component Article Name
AC/DC Power
4 TSP 600-148-M
Supply
USB to RS485
Adaptor TR
5 YN-485I-TR
Isolated
Water Cooling
6 WCM-i600.1
Module
PL-4089-00, Rev00, DCO# 21-271
Pump Head Driver
LPP-600.29 IPD-600.1-50-01
LPP-600.29 IPD-600.2-50-01
Table 1: Standard system configurations
Article # Characteristics
Impeller / Housing
Housing Sealing
Inlet / Outlet Fittings
100-91403 Max. Flow
Max. Diff.-Pressure
Max. Viscosity
Max. Liquid Temp.
Voltage, Power
Housing
Cable
Interfaces
100-10179
Standard Firmware
Housing
100-10180
Cable
Table 2: Specification of standard components
1: Designed and tested for IP67.
Article # Characteristics
Voltage / Power Output
100-40013 Voltage Input
Certification
Structure/Design
100-30392
Purpose
Materials
Motor Mounting Screws
Cooling Flow
190-10465
Pressure Drop
Max Static Pressure
Purpose
Table 3: Specification of accessories
Note
PFA pump head, Epoxy coated motor, 5 m PVC cable with open wires
PFA pump head, ETFE coated motor, 5 m FEP cable with open wires
Value / Feature
PFA / PFA
No sealing ring used. Pump housing is welded.
Tube 1"
75 liters/min / 20 gallons/min
3.1 bar / 45 psi
20 cP
90 °C / 194 °F
48 VDC ± 10%, 600 W
Epoxy (corrosion resistant) coated alu., waterproof (IP65)
PVC jacket, open wires, cable length 5 m
PLC - 1 analog input
with - 1 analog input
- 1 analog output
- 2 digital inputs
- 2 digital outputs
RS485 interface (for service and extended field operation).
Modbus protocol.
I1.48
ETFE (chemical resistant) coated alu., waterproof (IP65)
FEP jacket, open wires, cable length 5 m
Value / Feature
48 VDC / 600 W
85 – 265 VAC (automatic detection)
CB, UL, CSA, Semi F47
USB connector (A) with termination resistor and cable with
connector pair (B and C) for external RS485 wire
connection. Magnetically isolated. Cable length is 2m.
Included is a USB space saver cable (D).
Communication over fieldbus of driver with PC
PTFE coated stainless steel for plate (A) and scews (B).
4 x M4x16, Inox A4 (PTFE coated)
Min. 0.5 l/min at ≤ 20 °C. In-/outlet are NPT 1/8"x6.9mm.
0.13 bar at 1 l/min (for water at 20°C)
4 bar
Driver cooling at higher liquid temp. (see Section 3.4)
User Manual for BPS-i600
www.levitronix.com
4 – 20 mA
0 – 10 V OR 4 – 20 mA
0 – 10 V OR 4 – 20 mA
