Summary of Contents for Rice Lake 150-10-5
- Page 1 150-10-5 Digital Physician Scale Software Version 11525 Operation Manual August 18, 2022 PN 126150 Rev G...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
- Page 3 Established a revision history; formatted content to match other medical manuals; software version 11525 Table i. Revision Letter History Technical training seminars are available through Rice Lake Weighing Systems. Course descriptions and dates can be viewed at www.ricelake.com/training or obtained by calling 715-234-9171 and asking for the training department.
-
Page 4: Table Of Contents
6.0 Specifications ............... . . 15 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. -
Page 5: Introduction
Introduction Introduction The 150-10-5 digital physician scale is efficiently designed to provide accurate, reliable and repeatable weight measurements. It is equipped with a built-in height rod, a handle and two heavy-duty rear wheels for easy portability. Manuals, resources and warranties are available from Rice Lake Weighing Systems website at www.ricelake.com/health... -
Page 6: Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals. -
Page 7: Assembly
2. Thread the excess cable through the lower column to eliminate possible pinching during installation. Figure 2-1. Cabling Connecting the Scale Platform and Scale Column 3. Place the lower column on the base making sure not to pinch the cable. © Rice Lake Weighing Systems ● All Rights Reserved... - Page 8 150-10-5 Digital Physician Scale 4. Insert the screws through the bottom of the scale base to secure the column. Screw Hole Location Figure 2-2. Attach Column 5. Attach wheels to the wheel assembly rod. See Figure 2-3. 6. Attach the wheel assembly to the scale with a screw, tighten securely.
-
Page 9: Height Rod Installation
The six AA batteries that come with the scale offer an average of 25 hours of continuous use. To install the batteries: 1. Open the battery chamber cover by loosening the thumb screw. 2. Insert batteries. Figure 2-8. Batteries in Battery Chamber 3. Close the battery chamber cover. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 10: Ac Power Connections
Use the optional 120 VAC adapter or 230 VAC adapter when power is available. The optional AC power adapter plugs into the back of the indicator as shown below. Rice Lake Weighing Systems offers optional AC adapters, utilizing an adapter not supplied by Rice Lake Weighing Systems voids all warranties. -
Page 11: Operation
Pressing and holding Enter during startup will display ID. This is the first setup on entering into configuration mode. ENTER Up/Down Arrows Adjusts the value of the flashing digit/number. Adjusts height input (0.5 in/0.5 cm) while in BMI mode. Table 3-1. Scale Key Functions © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 12: Weighing
150-10-5 Digital Physician Scale Weighing Use the following steps to weigh a patient. 1. Press to turn on the scale. 0.0 displays along with ZERO on the upper display. 2. Have the patient step on the scale. The patient’s weight is displayed, the LOCK annunciator is on and the indicator beeps to indicate the end of the weighing process. -
Page 13: Troubleshooting
Note: Load cell connection point is located underneath the curved plastic cover of the indicator. Remove four back retaining screws, remove curved back cover to access load cell connection point. Table 3-2. Troubleshooting © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 14: Using The Height Rod
150-10-5 Digital Physician Scale Using the Height Rod The height rod can be extended to accommodate people of different heights and measures from 27.5 to 82 x 1/8 inch (70 to 208 x 1 mm). It is comprised of a stationary outer sleeve and an inner rod that slides up and stays in place once extended. - Page 15 Figure 3-4. Read Line Location For patients shorter than 43 in (109 cm), use the outer sleeve measurements (below the read line). Read Line Figure 3-5. Read Measurement for Patients Under 43 in (109 cm) © Rice Lake Weighing Systems ● All Rights Reserved...
-
Page 16: Communication
The unit comes with an RS-232 port that enables weight data to be transmitted to other equipment, such as a computer or printer. The RS-232 cable with DB-9 connector (PN 100719) is available from Rice Lake Weighing Systems. That connection is shown in USB Connection section on the next page. -
Page 17: Usb Connection
5. With weight on the scale, press and hold the Print button on the indicator for three seconds. The patient’s weight is sent to the PC. Figure 4-3. Patient Weight Displayed © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 18: Maintenance
150-10-5 Digital Physician Scale Maintenance The following section provides instructions for maintaining and cleaning the unit. Do not immerse the scale in cleaning or other liquid solutions. IMPORTANT Do not use Isopropyl alcohol or other solutions to clean the indicator display surface. -
Page 19: Specifications
14.7 in W x 14.7 in L x 3 in H (37.5 cm W x 37.5 cm L x 7.6 cm H) Overall Height 54 in (137.2 cm) Certifications and Approvals E113986 Complies with ANSI/AAMI ES60601-1:2005/A2:2010/(R)2012 CAN/CSA-C22.2 No. 60601-1:14 © Rice Lake Weighing Systems ● All Rights Reserved... - Page 20 150-10-5 Digital Physician Scale www.RiceLake.com Visit our website...
- Page 22 © Rice Lake Weighing Systems Specifications subject to change without notice. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319 August 18, 2022 PN 126150 Rev G...
