Summary of Contents for sauter equitherm EQJW 125

Page 2 EQJW 125: Heating controller User's Manual 7001029003 A...
Page 3 7001029003 A Printed in Switzerland Subject to changes © Fr. Sauter AG Im Surinam 55 CH - 4016 Basel www.sauter-controls.com 7001029003 A © Fr. Sauter AG...
Page 4: Table Of Contents
Display when OFF mode, reduced mode and normal mode are set ..33 Entering the setpoint temperature in normal mode......... 34 Entering the setpoint temperature in reduced mode....... 35 Weekly switching programme ..............35 4.4.1 Calling up the weekly switching programme........... 36 7001029003 A © Fr. Sauter Ltd.
Page 5 Setting parameters using the PC ............51 Faults ........................52 Displaying faults ..................52 7.1.1 Error list ....................52 7.1.2 Device status................... 52 Reset functions ..................53 Actions to deal with faulty temperature readings ........53 Application ......................54 7001029003 A © Fr. Sauter AG...
Page 6 List of SERVice parameters ..............66 15.2 List of communication parameters ............67 15.3 Weekly switching programme ..............68 15.4 Calendar switching programme .............. 68 List of figures ......................69 List of tables......................70 Abbreviations......................71 Index .......................... 72 7001029003 A © Fr. Sauter Ltd.
Page 8: Symbols Used In This Manual
The operating instructions give a step-by-step explanation of the individual functions of the device, with the help of the following symbols: 'PROG' is shown on the display, flashing '09:00' is shown on the display, not flashing Press key..7001029003 A © Fr. Sauter Ltd.
Page 10: General Information
SERVice parameters. An automatic change-over between summer and winter time relieves residents of the need to correct the time twice a year. The equitherm EQJW 125 contains various protective functions such as the anti-frost function and the anti-jamming function for the pump.
Page 12: Description Of The Controls
EQJW125 °C 50 C Fig. 1: Front view of the EQJW 125 Rotary switch Display ESC button Input knob The device has a rotary switch with 10 positions, an input knob and a button. 7001029003 A © Fr. Sauter Ltd.
Page 13: Rotary Switch
ESC button You can use the ESC button to cancel procedures or to return from a subordinate menu item to the next level up. 7001029003 A © Fr. Sauter AG...
Page 14: Display
Display of flow temperature Display of outdoor temperature Display of room temperature Controller is in summer mode Calendar switching programme is currently active An error has occurred (see Section 7) Funktion Floor-drying (operational heating) is active 7001029003 A © Fr. Sauter Ltd.
Page 16: Commissioning
• Press the input knob; year is confirmed and day/month are • shown Turn the input knob; the date is changed • Push the input knob; new date is confirmed • 7001029003 A © Fr. Sauter Ltd.
Page 17: Service Mode
Turn the input knob; Select the SERVice parameter that you want Push the input knob; the value for the parameter is shown • To leave the value unchanged, exit from the display by pushing ESC. 7001029003 A © Fr. Sauter AG...
Page 18: Changing Service Parameters
0 = no room temperature detection 1 = connection of NI1000 room sensor 2 = Connection for EGS 52/15 or EGT 333 with room sensor 3 = Connection for EGS 52/15 or EGT 333 w/o room sensor 7001029003 A © Fr. Sauter Ltd.
Page 19: Tab. 1: Service Parameters
P23 = P24 means no summer/winter time change-over SP60 Floor drying 0;7d; 25°C; 8;9 0;7d; 25°C; 8;9 0 = not enabled 7d = functional heating 25°C = ready for laying 8 = malfunction 9 = successfully completed Tab. 1: SERVice parameters 7001029003 A © Fr. Sauter AG...
Page 21: Explanations Of Service Parameters
Modbus. In the event of contradictory commands, the following priorities apply: (i) the settings on the EQJW 125 itself have priority 1; (ii) the settings via the EDB 100 room operating unit via the device 7001029003 A © Fr. Sauter AG...
Page 22 ) of the PI control for the flow temperature in K. Integral action time SP13 SERVice parameter 13 determines the integral action time (T ) of the PI control for the flow temperature in seconds. 7001029003 A © Fr. Sauter Ltd.
Page 23: Fig. 3: Guideline For The Slope Of The Heating Characteristic
Valves with a motorised actuator need a certain time (known as the valve run-time) to open or close completely. This SERVice parameter is used to set the equitherm EQJW 125 to the run-time for the valve drive that is being used. Optimal control quality and various protective functions are only ensured if the valve run-time is set correctly.
Page 24 0, it is disabled. The factory setting for this parameter is 1. Summer/winter or winter/summer time-change SP23, P24 Thanks to the calendar time-switch integrated into the equitherm EQJW 125, the winter/summer time-change and the summer/winter time-change are carried out automatically. The date for the change-over is specified by the value for SERVice parameters SP23 and SP24.
Page 25 When the floor-drying function has been successfully completed, the figure 9 appears. If the floor-drying function was interrupted (due to a sensor failure or high control deviation over a long period etc.), 8 is displayed (instead of 9) as the error message. 7001029003 A © Fr. Sauter AG...
Page 26: Communication Mode
Set rotary switch to Service position. Turn the input knob. Select 'CO' (COmmunication). Push the input knob. Turn the input knob. Show the code. Push the input knob. The first communication parameter is • shown. 7001029003 A © Fr. Sauter Ltd.
Page 27: Viewing The Communication Parameters
The value of the parameter is changed. • Push the input knob. The new value is confirmed. • Push the ESC button to cancel the procedure. The value will not be accepted unless it has already been confirmed. 7001029003 A © Fr. Sauter AG...
Page 28: List Of Communication Parameters
Device bus: EDB 100 digital room operating unit CP15 0…1 0 = EDB 100 not connected, 1 = EDB 100 connected CP16 – Device bus: address of EDB 100 room operating unit auto, 2…32 7001029003 A © Fr. Sauter Ltd.
Page 29: Explanations Of Communication Parameters
The type of communication can be set. You can choose from these options: 0 = no communication 1 = device bus 2 = MOD bus via RS485 3 = MOD bus via modem 4 = SMS via modem 5 = MOD bus and SMS via modem 7001029003 A © Fr. Sauter AG...
Page 30 Device bus: send outdoor temperature CP10 If CP 10 is set to 1, this controller sends the current outdoor temperature on the device bus. 7001029003 A © Fr. Sauter Ltd.
Page 31 SMS or Modbus via modem: modem time-out CP19 In case of a connection via modem, the connection is terminated by the controller if no data exchange has taken place after this time has elapsed. 7001029003 A © Fr. Sauter AG...
Page 32 Modbus become invalid after 30 minutes and the controller operates independently of the control station again. If CP24 = 0, the operating statuses continue to have unlimited validity even beyond these 30 minutes. 7001029003 A © Fr. Sauter Ltd.
Page 33: Operation
This is mainly needed for commissioning or in case of faults on the plant. Normal mode corresponds to nominal mode as per EN12098-1. 7001029003 A © Fr. Sauter AG...
Page 34: Display When Off Mode, Reduced Mode And Normal Mode Are Set
In special cases, more displays can be added to the display loop, e.g. display (see section 7) can be added in case of a fault, a display of the connection status can be added for modem operation. 7001029003 A © Fr. Sauter Ltd.
Page 35: Entering The Setpoint Temperature In Normal Mode
Push the input knob and the numerical value will flash... …and you can now change it by turning it upwards or downwards (step value: 0.1°C). Push the input knob again to confirm the changed numerical value. 7001029003 A © Fr. Sauter AG...
Page 36: Entering The Setpoint Temperature In Reduced Mode
The ex-works setting for the weekly programme is: Time Mode Daily 06:00 Normal mode Daily 22:00 Reduced mode You are recommended to note any change to the weekly switching programme in the relevant table in Section 14. 7001029003 A © Fr. Sauter Ltd.
Page 37: Calling Up The Weekly Switching Programme
Push the input knob. The time for the switching command is • confirmed. Turn the input knob. Select the mode for the switching command. Push the input knob. The mode is confirmed. • 7001029003 A © Fr. Sauter AG...
Page 38: Changing And Deleting A Switching Command
The switching commands are captive. You are recommended to note any change to the calendar switching programme in the relevant table in Section 14. No commands are entered in the calendar switching programme in the ex-works setting. 7001029003 A © Fr. Sauter Ltd.
Page 39: Viewing Switching Commands
Push the input knob. The date for the switching command is • confirmed. Turn the input knob. Select the mode for the switching command. Push the input knob. The mode is confirmed. • 7001029003 A © Fr. Sauter AG...
Page 40: Changing And Deleting A Switching Command
After the temporary temperature change has finished, the heating circuit is again controlled in accordance with the automatic mode. Use the ESC button or set the rotary switch to another position to cancel the temporary temperature change function. 7001029003 A © Fr. Sauter Ltd.
Page 41: Manual Mode
Push the input knob. Select the menu option. Turn the input knob. specify pump output (0 = pump off, 1 = pump on). Push the input knob. The setting is accepted. • 7001029003 A © Fr. Sauter AG...
Page 42: Ending Manual Mode
Select the 'INFO' menu option. Turn the input knob; the individual values are shown. The display loop is the same as for the 'automatic mode' switch position. Push the 'ESC' button. Exit from the 'INFO' menu option. 7001029003 A © Fr. Sauter Ltd.
Page 43: Communication Functions
CP04. The following should be observed when automatically assigning addresses:- All other devices in the installation must be switched on. Only one device should carry out the function in each case. 7001029003 A © Fr. Sauter AG...
Page 44: Edb 100 Room Operating Unit
The EQJW 125 can respond to enquiries in the Modbus RTU protocol as a slave. For this purpose, an RS-485 two-wire bus is connected to terminals 18 and 19. A suitable Modbus master (BMS centre) can send enquiries or commands via this bus. 7001029003 A © Fr. Sauter Ltd.
Page 45 Current measured values and operating statuses (for example) can be read out via Modbus. The controller outputs can be switched. The list of the available data points is given in the Annexe, section 6.3.1. 7001029003 A © Fr. Sauter AG...
Page 46: Modbus Data Points (Holding Register)
3=Manual, 4=Normal, 5=Reduced 40106 Mode_Rk1 1=Auto, 2=Stdby, 3=Manual, 4=Sun, 5=Moon 40107 ControlSignal_Rk1 Opening for control signal [0...100%] Value T A heating switch-off 40117 AT_HeatOff_Rk1 °C 40145 Write-En_Modem Write enable for modem (code number input) 7001029003 A © Fr. Sauter Ltd.
Page 47: Tab. 3: Modbus Data Points
48 possible switching commands for the 1 42047 commands heating circuit 42500 to Calendar switching 20 possible switching commands for the 42519 program calendar switching program Tab. 3: Modbus data points The data points are transmitted in 16 bits. 7001029003 A © Fr. Sauter AG...
Page 48: Tab. 4: Switching Commands
Examples To change the factory setting for the first switching command (every day, as from 6:00 hrs, nominal operation) to 7:30 hrs, the value 30730 (instead of 30600) should be written in register 42042. 7001029003 A © Fr. Sauter Ltd.
Page 49: Modbus Data Points (Coils)
Bit for setpoint value Calculation of the setpoint value for Auton. specified Manual mode Enable manual mode Inactive Active Disable modem Dialling the control station via modem Inactive Active if a fault occurs is disabled (see CP23) 7001029003 A © Fr. Sauter AG...
Page 50: Modem Operation
In the event of an error, the control station is called on the telephone number entered at CP06. The line between the controller and the modem must not be longer than 1.5 m for reasons related to EMC. 7001029003 A © Fr. Sauter Ltd.
Page 51: Sending Sms If There Is A Fault On The Plant
CP07 and CP08. (see section 3.3). No guarantee is given of the availability and correctness of these numbers. Up-to- date information on this subject must be requested from the network operator. 7001029003 A © Fr. Sauter AG...
Page 52: Displays For Modem Operation
It is not possible to communicate with non-configured controllers if there are several controllers in a network that have not yet been configured. In such cases, all but one of the controllers that have not yet been configured has to be switched off beforehand. 7001029003 A © Fr. Sauter Ltd.
Page 53: Faults
Err 2 (Sensor failure T A ) Err 3 (Sensor failure T R ) Err 11 (Prohibited access) 1024 The value shown as the device status is the total of the codings for the existing errors. 7001029003 A © Fr. Sauter AG...
Page 54: Reset Functions
If the flow temperature sensor is faulty, the valve assumes the 30% valve Flow temperature sensor position. If the room sensor fails, the controller operates according to the settings for Room temperature sensor operation without a room sensor. 7001029003 A © Fr. Sauter Ltd.
Page 55: Application
An input knob makes it easy to change the device's settings. Plant schematic Fig. 4: Plant schematic EQJW 125 heating controller Final control element Drive Heating medium pump Flow temperature sensor Outdoor temperature sensor Room sensor or room remote control unit (if present) 7001029003 A © Fr. Sauter AG...
Page 56: General Information
SERVice parameter SP16 value 50°C The recommended values have been tried and tested but they are not necessarily the ideal solutions for every plant. No liability is accepted for the values indicated here. 7001029003 A © Fr. Sauter Ltd.
Page 57: Economy Tips
6% of heating costs. Only ventilate briefly, but well. Close shutters and blinds at night. Keep heaters clear, i.e. do not place any furniture or curtains in front of the heaters, etc. 7001029003 A © Fr. Sauter AG...
Page 59: Resistance Values For The Ni1000 Sensors
The temperature coefficient is always positive, i.e. the resistance increases as the temperature rises. See the table of values (DIN 43760). Within the specified tolerances, the sensors can be exchanged without calibration. 7001029003 A © Fr. Sauter AG...
Page 61: Accessories
EQJW 125: Heating controller Accessories Accessories See the Sauter PDS for more components. Wiring diagram EQJW125 MODEM 27 28 27 28 27 28 27 28 EGS 52/15 EGT 333 EGS 52/15 EGT 333 A10175a Fig. 6: Wiring diagram Dimension drawing 138 ×...
Page 63: Technical Data
6 per day or 48 per week weekly programme Switching period for calendar prog. 1 day Number of switching commands in calendar programme Inputs: 2 temperature sensors Ni1000 1 temperature sensor or remote control Ni1000 panel 7001029003 A © Fr. Sauter AG...
Page 64: Tab. 9: Overview Of Technical Data
SP 18 Zero-point correction for room temp up to ± 6 K is possible Zero-point correction for outside temp. up to ± 9 K is possible Tab. 9: Overview of technical data 7001029003 A © Fr. Sauter Ltd.
Page 65: Overview Of Main Functions
The operating mode from the weekly and yearly switching programmes with the lower energy consumption has priority. An 'empty' switching programme is interpreted as normal mode. The yearly switching programme is enabled in the SERVice level. In the ex-works setting, the yearly 7001029003 A © Fr. Sauter AG...
Page 66 Alarms via SMS telephone, via a provider. An interface similar to an RS 232 is used for this purpose. The TAP protocol (Telocator Alphanumeric Protocol) is used here. The settings are made in the communication level. 7001029003 A © Fr. Sauter Ltd.
Page 67: Overview Of Controller Settings
SP07: ______ SP20: ______ SP08: ______ SP21: ______ SP09: ______ SP22: ______ SP10: ______ SP23: 25.10 ______ SP11: ______ SP24: 25.03 ______ SP12: ______ SP60: ______ SP13: ______ Tab. 10: List of SERVice parameters 7001029003 A © Fr. Sauter AG...
Page 68: List Of Communication Parameters
CP06: ______ CP19: ______ CP07: ______ CP20: ______ CP08: ______ CP21: ______ CP09: ______ CP22: ______ CP10: ______ CP23: ______ CP11: ______ CP24: ______ CP12: ______ CP13: ______ Tab. 11: List of communication parameters 7001029003 A © Fr. Sauter Ltd.
Page 69: Weekly Switching Programme
____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ ____________ 7001029003 A © Fr. Sauter AG...
Page 70: List Of Figures
Fig. 3: Guideline for the slope of the heating characteristic: ........22 Fig. 4: Plant schematic ....................54 Fig. 5: Energy consumption in the home ..............56 Fig. 6: Wiring diagram....................60 Fig. 7: Dimension drawing ..................60 7001029003 A © Fr. Sauter Ltd.
Page 71: List Of Tables
Tab. 7: Error list ......................52 Tab. 8: Resistance value Ni1000................58 Tab. 9: Overview of technical data ................63 Tab. 10: List of SERVice parameters ................. 66 Tab. 11: List of communication parameters ............... 67 7001029003 A © Fr. Sauter AG...
Page 72: Abbreviations
T Rmax minimum limit for the adjusting range for T Rmin setpoint for the room temperature heating limit valve run-time proportional band setpoint 7001029003 A © Fr. Sauter Ltd.
Page 73: Index
Heat requirement ..................29 Heating characteristic...................21 Heating limit ...................21, 62 Holidays .......................36 index ......................71 Installation instructions .................. 9 Key........................ 7 LC display ....................13 Limitation......................19 Manual mode ..................19, 63 Maximum limitation..................21 Measuring accuracy ..................62 Minimum limitation..................21 7001029003 A © Fr. Sauter AG...
Page 74 ......................43 Switching command .................19, 36, 47 Switching programme ...................63 technical data ....................61 Temperature level ..................9 terminal resistance ..................41 Time constant....................62 Time synchronisation ...................28 Valve runtime ....................21 weekly switching programme ...............67 wiring diagram....................59 7001029003 A © Fr. Sauter Ltd.
