Component Locator Views
Gas Model
Inlet Thermistor
Drum Roller
Combustion Chamber
Hi-Limit Thermostat
Idler Pulley
Drive Motor
Outlet Thermistor (behind frame)
Outlet Thermostat (behind frame)
Gas Valve
Blower Wheel
Flame Sensor Detector
Ignitor
Inlet Safety Thermostat
Manual Reset
(Continued Next Page)
– 13 –
