To reverse the door swing:
1. Open the door and remove the fi ller plugs
opposite the hinges.
2. With the door completely open, remove the
bottom screw from each hinge on the dryer
face.
3. Insert the screws about halfway into the top
holes, for each hinge, on the opposite side
(where you removed the fi ller plugs). Apply fi rm
pressure to get the screws started in the new
holes.
4. Loosen the top screw from each hinge on the
dryer face halfway. With one hand holding the
top of the door and the other hand holding the
bottom, remove the door from the dryer by
lifting it up and out.

Reversing the Door Swing

5. Remove the screws holding the handle and two
6. Remove the door catch and fi ller plate. Install
– 10 –
spacers.
Rear of Door
them on opposite sides of the door.
Filler
Plate
Catch
(Continued Next Page)
