PARTS AND TOOLS
K
SUPPORT OF
MOUNTING
1
Mark with a pencil the 4 holes of the piece
K in the roof.
3
Place the washer and then the
screw M2.
5
Repeat this step on all 3 holes
remaining.
STEP 1. WOOD ROOF
M
(2) WOOD SCREWS
K
M2
x4
MATERIAL NOT INCLUDED
+
+
2
If necessary, depending on the type of
roof, you will need to use a drill to make the
hole in the wood.
4
With the help of the screwdriver tighten
the screws M2.
6
Make sure the part K It is perfectly hooked
to the ceiling and that no cable is trapped.
OPTIONAL ACCORDING TO
TYPE OF ROOF
M2
K
