Step 4. Blade Assembly - Create WIND HELIX Assembly Manual

E
(x3) BLADES
1
H
With the motor well placed,
we will begin the assembly
of the blades E.
4
Do the same step with all the blades E. Once all the blades are placed E, tighten all screws
well Q so that the blades are well attached.

STEP 4. BLADE ASSEMBLY

+ +
2
E
Place the first blade E fastening it with the washers and the
screws Q with the help of the screwdriver, without tighten-
ing them too much, to be able to put the rest.
5
Q
(x7) BLADE SCREWS
Q
3
6
