Step 1. False Ceiling - Create WIND HELIX Assembly Manual

PARTS AND TOOLS
K
SUPPORT OF
MOUNTING
1
Mark the 2 central holes of the piece on
the ceiling with a pencil K using the same
piece as a guide.
3
X
Insert the fixing screws into the holes and
make sure that the lever opens.
5
EN ENGLISH

STEP 1. FALSE CEILING

+
FIXING SCREWS
WITH SPRING LEVER
K
K
MATERIAL NOT INCLUDED
+
2
With the help of a drill, make the 2 corre-
sponding holes.
4
Place the piece K and screw the fixing
screws to the false ceiling.
Make sure the part K is perfectly attached
to the ceiling to be able to continue with
the assembly.
+
