I J
+
TILT SUPPORT
1
I
Using a screwdriver, remove the two screws on the bar tilt
bracket I.
4
Remove the pin from the tilt
bracket.
7
Carefully pull the pin out of
the bar I.

CHOICE OF GRAB BAR

Before you start, choose the desired height.
(10cm+/-)
You will have to choose between the height of the
piece Yo wave J.
+
· If you choose the height of the piece J, You must
follow the instructions below.
· If you choose the height of the piece I, go directly
to step 2 (page 12).
2
J
I
5
Pull out the bracket
bar tilt I.
8
Attach the tilt bracket to
the bar J.
3
Slide the tilt stand down.
6
Pull out the bar pin locking
piece I.
9
J
Place the pin of the tilt sup-
port on the bar J.
J
