Create WIND HELIX Assembly Manual page 13

4
L
insert the piece L As shown
in the picture.
7
With the help of a screw-
driver, remove the 2 screws
from the top of the piece H.
10
Once the seatpost has been
inserted, place the pin of
the piece I/J so that it co-
incides with the hole in the
bar.
5
H
Once the pieces are inserted A Y L, you must insert the ca-
bles of the part H inside the bar. If you want, you can tape the
wires down to make it more
easy to pass them inside.
8
H
H
Insert the seatpost into the
top of the piece H.
11
H
Put the pin in the lock piece
so that it does not come out.
6
H
9
H
Make sure no wires get
pinched.
12
H
Then replace the
screws so that the bar is ful-
ly attached.
