REP 4.7 Versant Error Messages

Does the Versant User Interface display a fault showing "The original size could
not be detected..."?
N Y
Adjust the Versant Paper Tray Guides (plastic guides) to meet or "hug" the Envelope Feeder
Side Guides.
Does the Versant User Interface display a fault showing "Paper Size/Orientation
in Tray 5 is Different..."?
N Y
Adjust the length value and width value on the Versant Paper Tray Attributes screen (on
the Versant User Interface) to match the actual media loaded in the Hopper.
NOTE: If the envelope size is measured in hundredths-of-an-inch (for example, 4.75), you may
be required to try a slightly larger size (4.8) on the Versant User Interface (since the Versant
User Interface only accepts sizes measured in tenths-of-an-inch).
IMPORTANT: the side guides on the feeder actually need to be slightly wider than the envelope.
Similar to the side guides on the feeder discharge assembly, the side guides in the hopper must
be set with approximately ¼" of additional space to ensure envelopes are not "squeezed" in the
hopper (see below).
Go to the top of the next page.
Xerox Customized Envelope Feeder – Problem Solving Guide
¼" gap
