OWNER'S MANUAL & INSTALLATION INSTRUCTIONS
Important Installation Information:
The Dallas Retro
®
part between Projection Bar (BP) and Top Bar (TB). Please read instructions fully
before installing.
NOTE: Please inspect the parts for damage during shipping and/or for any missing items. If you suspect
that there may be damage or a shortage, contact us and we will send replacement parts if needed. At
this time, visualize how the components fit together and make sure that you have identified the various
parts.
Models with Valance:
RR12, RR22, ER23, CR32, CR34, CR43, CR44, ER2442, ER12, ER1836, ER1230, ER1230, ER1030,
ER24, CR33
Models without Valance:
RR12-NV, RR22-NV, ER23-NV, CR32-NV, CR34-NV, CR43-NV, CR44-NV, ER2442-NV, ER12-NV,
ER1836-NV, ER1230-NV, ER1030-NV, ER24-NV, CR33-NV
Awning size
3
4
5
6
7
8
9
10
11
OUR AWNINGS ARE DESIGNED 4.5" WIDER THAN STANDARD WINDOW/DOOR
OPENINGS SO THEY ANCHOR TO THE STUDS AROUND THE WINDOW OR DOOR.
EXAMPLE: RR22-5 IS FOR 5'-0" WIDE WINDOW. IT MEASURES 64.5" WIDE, 31" TALL, (24"
1
The Dallas Retro
frame must be installed on the wall as there is no connecting
Width in inches
40.5
52.5
64.5
76.5
88.5
100.5
112.5
124.5
136.5
PLUS 7" VALANCE AND 24" DEEP (PROJECTION)
Style Awning
®
Awning Size
Width to Inches
12
13
14
15
16
17
18
19
20
148.5
160.5
172.5
184.5
196.5
208.5
220.5
232.5
244.5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Awntech Dallas Retro RR12
Summary of Contents for Awntech Dallas Retro RR12
- Page 1 The Dallas Retro Style Awning ® OWNER’S MANUAL & INSTALLATION INSTRUCTIONS Important Installation Information: The Dallas Retro frame must be installed on the wall as there is no connecting ® part between Projection Bar (BP) and Top Bar (TB). Please read instructions fully before installing.
- Page 2 There are a variety of building wall surfaces, Awntech® does not supply the hardware to install your awning. You will need to purchase installation hardware at your local hardware store. We have advised you on different surface applications below: There are a variety of building wall surfaces, Awntech does not supply the hardware to install your awning. You will need to purchase installation hardware at your local hardware store.
- Page 3 The Dallas Retro® frame must be installed on the wall as there is no connecting part between Projection Bar (BP) and Top Bar (TB) STEP 1: Separate all of the parts, so they will be easy to assemble. STEP 2: The Top Bar (TB) must be installed first. Mount Provided Z-Brackets to surface, and insert TB into brackets. The C-Channel must be close to the wall.
- Page 4 STEP 3: Insert the L shaped plastic ends of the Front Bar (FB) in to Left and Right Black Projection Bar (BP) and then secure them with self-tapping screws. The Velcro on the front bar (FB) faces towards you. *Note: On earlier models, the Velcro will be on top of the front bar (FB), Pay close attention to the black angle ends.
- Page 5 ***all the sizes are in inches Space Space between Height between Height Model TB and incl. Projection Model TB and incl. Projection BP in Valance BP in Valance inches inches RR22 RR22-NV CR32 CR32-NV CR33 CR33-NV CR34 CR34-NV CR43 CR43-NV CR44 CR44-NV ER2442...
- Page 6 Frame 2’-5’ Frame 6’-20’ INSTALLING THE COVER STEP 6: Slide the tubing at the top of the fabric cover into the C-Channel on the top of (TB). STEP 7: Pull the remainder of fabric over the fame with the valance hanging down below the (NC) and (FB) bars.
- Page 7 •Promptly notify Awntech Corporation of any claims. •At Awntech’ s request the purchaser may be required to provide a photographs or videos (if necessary) of any defective parts. The purchaser may also be required to pay a deposit until the defective parts are returned to Awntech Corporation for...
- Page 8 Awntech Corporation shall have been advised of the possibility or likelihood of such potential loss or damage. In no event shall Awntech Corporation be liable for loss of profits and/or wages.
