The Dallas Retro
Important Installation Information:
The Dallas Retro Frame must be installed on the wall as there is
no connecting part between BP and TB
ASSEMBLY AND INSTALLATION INSTRUCTIONS
CAUTION: When you are opening the box keep children away. This
awning frame contains sharp metal and small hardware parts.
Choking hazard: Keep parts away from children. They may choke on
hardware. Be extremely cautious around children.
Models with Valance:
RR22, ER23, CR32, CR34, CR43, CR44, ER2442, ER12, ER1836, ER1230, ER1030, ER24,
CR33
Models without Valance:
RR22-NV, ER23-NV, CR32-NV, CR34-NV, CR43-NV, CR44-NV, ER2442-NV, ER12-NV, ER1836-
NV, ER1230-NV, ER1030-NV, ER24-NV, CR33-NV
All the awning sizes over 9' wide come in two sections. Example: Top Bar (TB) consists of
TB1 & TB2 and Front Bar (FB) consists of FB1 & FB2
See the chart below for the width of the awning:
Width in inches
Awning Size
3
40.5
4
52.5
5
64.5
6
76.5
7
88.5
8
100.5
9
112.5
10
124.5
11
136.5
OUR AWNINGS ARE DESIGNED 4.5" WIDER THAN STANDARD
WINDOW/DOOR OPENINGS SO THAT YOU WILL BE ANCHORING INTO
THE STUDS AROUND THE WINDOW OR DOOR. EXAMPLE: RR22-5 is for a
5'-0" wide window. It measures 64.5" wide, 31" tall (24" plus 7" valance) and 24"
deep (projection).
Style Awning
®
Width in inches
Awning Size
12
148.5
13
160.5
14
172.5
15
184.5
16
196.5
17
208.5
18
220.5
19
232.5
20
244.5
Advertisement
Related Manuals for Awntech The Dallas Retro RR22
Summary of Contents for Awntech The Dallas Retro RR22
- Page 1 The Dallas Retro Style Awning ® Important Installation Information: The Dallas Retro Frame must be installed on the wall as there is no connecting part between BP and TB ASSEMBLY AND INSTALLATION INSTRUCTIONS CAUTION: When you are opening the box keep children away. This awning frame contains sharp metal and small hardware parts.
- Page 2 Due to the fact that there is such a variety of building wall surfaces, Awntech does not supply the hardware to install your awning. You will need to purchase installation hardware at your local do-it- yourself center. We have advised you on different surface applications below: CONCRETE BLOCK WALLS: (1) ½”...
-
Page 3: Installing The Cover
The Dallas Retro Frame must be installed on the wall as there is no connecting part between BP and TB STEP 1: Separate all of the parts by part number so they will be easy to assemble. STEP 2: The Top Bar (TB) must be installed first. The C-Channel on the TB must be close to the wall. -
Page 4: Warranty
(a) Should the purchaser promptly notify Awntech Corporation of such defects within one year (12 months) from the date of the original purchase, the defective component will be replaced at no charge. Awntech reserves the right to ask for the defective part to be returned and/or photos of the defective part. - Page 5 Awntech in re- stockable condition. If DAMAGED MATERIAL: Damage occasionally occurs during shipping.
- Page 6 DALLAS RETRO STYLE AWNINGS MUST BE ASSEMBLED ON THE BUILDING For frames sizes 2’ – 4’...
- Page 8 For frame sizes 5’- 7’. Additional parts will be enclosed for the large size awnings such as NC, BP...
