OWNER'S MANUAL & INSTALLATION INSTRUCTIONS
WARNING: Adult Assembly Required
WARNING: Assembly Kit Contains Parts with Sharp Points, Sharp Edges, and Small Parts That Can
Present Choking Hazards to Children.
WARNING: Components Are Packed in Plastic Bags that are a Suffocation Hazard.
NOTE: Please inspect the parts for damage during shipping and/or for any missing items. If you suspect
that there may be damage or a shortage, contact us and we will send replacement parts if needed. At
this time, visualize how the components fit together and make sure that you have identified the various
parts.
Models with Valance:
RN22, EN23, EN24, CN32, CN33, CN34, CN43, CN44, EN2442, EN1836, EN1030
Awning size
3
4
5
6
7
8
9
10
11
OUR AWNINGS ARE DESIGNED 4.5" WIDER THAN STANDARD WINDOW/DOOR OPENINGS SO THEY
ANCHOR TO THE STUDS AROUND THE WINDOW OR DOOR. EXAMPLE: RR22-5 IS FOR 5'-0" WIDE
WINDOW. IT MEASURES 64.5" WIDE, 31" TALL, (24" PLUS 7" VALANCE AND 24" DEEP (PROJECTION)
There is a variety of building wall surfaces; Awntech does not supply the hardware to install your
awning. You will need to purchase installation hardware at your local hardware store. We have advised
you on different surface applications below:
1
New Yorker Style Awning
Width in inches
40.5
52.5
64.5
76.5
88.5
100.5
112.5
124.5
136.5
Awning Size
Width to Inches
12
13
14
15
16
17
18
19
20
148.5
160.5
172.5
184.5
196.5
208.5
220.5
232.5
244.5
Advertisement
Related Manuals for Awntech New Yorker
Summary of Contents for Awntech New Yorker
- Page 1 WINDOW. IT MEASURES 64.5” WIDE, 31” TALL, (24” PLUS 7” VALANCE AND 24” DEEP (PROJECTION) There is a variety of building wall surfaces; Awntech does not supply the hardware to install your awning. You will need to purchase installation hardware at your local hardware store. We have advised...
- Page 2 NOTE: YOU WILL FIND THAT THE FITTINGS HAVE BEEN PRE-INSTALLED, AS WE HAVE PRE-ASSEMBLED AND INSPECTED IT FOR YOU IN THE FACTORY. New Yorker should be assembled on the ground STEP 1: Separate all of the parts, so they will be easy to assemble. Please refer to Parts chart for...
- Page 3 Step 2: Connect Top Bar (TB) to the (2) two back bars (CNB). Make sure the C-Channel is towards the back. The Velcro on the back bars should be facing front. Use a rubber mallet to fully seat the tubing into the fitting.
- Page 4 Step 3: Insert the Projection Bars (CNP) in to the bottom slots Velcro facing up, and insert the Projection assembly (CNPA) in to the top slots of your front bar assembly. Frame 2’-4’ Frame 5’-24’ Step 4: Connect the Front Bar Assembly on to the Back Bar Assembly. Secure with Self tapping screws. Frame 2’-4’...
- Page 5 You can decide where to install your wall supports and attach them using self tapping screws to the bottom/back end of your front bar assembly. Frame 2’-4’ Frame 5’-24’ The frame for the New Yorker is complete Frame 2’-4’ Frame 5’-24’...
-
Page 6: Installing The Cover
INSTALLING THE COVER STEP 6: Slide the tubing at the top of the fabric cover into the C-Channel on the top of (TB). STEP 7: Pull the remainder of fabric over the fame with the valance hanging down below the (NC) and (FB) bars. -
Page 7: Mounting The Awning
STEP 8: Once you are satisfied with the position of the cover, Pull the tabs snugly and attach them to the pre-installed Velcro tape on the bars. MOUNTING THE AWNING STEP 9: Place the awning on in desired location. From the inside of the awning make a mark on the wall where the awning touches. -
Page 8: Cleaning And Care
Step 10: install the Z-Brackets, temporarily place the awning on the wall to make sure it fits prior to tightening screws. Please keep in mind there are no pre-drilled holes for the Z-Brackets on the frame. You'll use the provided self tapping screws to secure the Z-Bracket to the frame. Step 11: Remove the awning and tighten wall brackets. - Page 9 CLEANING CHART FOR TYPICAL AWNING STAINS STAIN RECOMMENDED CLEANING SOLUTIONS CHARCOAL Vacuum, then liquid detergent CHEWING GUM Acetone SODA Liquid detergent CAR GREASE Acetone IRON RUST Oxalic or citrus acids, water MILDEW 1 cup of bleach and ¼ mild soap per gallon of water Acetone PAINT (LATEX) WET Liquid detergent, water...
