Awntech RN22 Owner's Manual & Installation Instructions

OWNER'S MANUAL & INSTALLATION INSTRUCTIONS

WARNING: Adult Assembly Required

WARNING: Assembly Kit Contains Parts With Sharp Points, Sharp Edges, and Small Parts That Can Present Choking
Hazards to Children.
WARNING: Components Are Packed In Plastic Bags That are a Suffocation Hazard.
NOTE: Please inspect the parts for damage during shipping and/or for any missing items. If you suspect
that there may be damage or a shortage, contact us and we will send replacement parts if needed. At
this time, visualize how the components fit together and make sure that you have identified the various
Parts.

Models with Valance:

RN22, EN23, CN32, CN43, CN34, CN44, EN2442, EN12, EN1836, EN1230, EN1030, EN24, CN33, NY1618, NY1624,
NY1630, NY1818, NY1830, NY2430, NY2436, NY3024, NY3030, NY3036, NY3048, NYCUSTOM
Awning size
3
4
5
6
7
8
9
10
11
OUR AWNINGS ARE DESIGNED 4.5" WIDER THAN STANDARD WINDOW/DOOR OPENINGS SO THEY ANCHOR TO THE
STUDS AROUND THE WINDOW OR DOOR. EXAMPLE: RR22-5 IS FOR 5'-0" WIDE WINDOW. IT MEASURES 64.5"
WIDE, 31" TALL, (24" PLUS 7" VALANCE AND 24" DEEP (PROJECTION)
There are a variety of building wall surfaces, Awntech does not supply the hardware to install your awning. You
will need to purchase installation hardware at your local hardware store. We have advised you on different
Surface Applications below:
1
New Yorker Style Awning
Width in inches
40.5
52.5
64.5
76.5
88.5
100.5
112.5
124.5
136.5
Awning Size Width to Inches
12 148.5
13 160.5
14 172.5
15 184.5
16 196.5
17 208.5
18 220.5
19 232.5
20 244.5
