LTPH-UM-1208-01

Clearing the History, Alarm, and Event Log Screens

Select Master Clear to clear the History, Alarm, and Event Log screens after the system has been installed and is
functioning properly. This removes miscellaneous data acquired during the start-up session and ensures that you
have meaningful data thereafter.
To clear the Event Log, press
To clear an individual history or alarm screen, do the following:
1 Press P to select the Performance screen.
2 Press the SPACEBAR
H2TU-R HDSL2), then press
3 Press ↓ to select statistics.
4 Press the SPACEBAR
48-Hour History, or 31-Day History), and press
–
Selecting 31-Day History allows you to clear the current, 25-hour, 48-hour, and 31-day
performance history screens for the selected interface.
–
Selecting Alarm History allows you to clear the alarm history screen for the selected interface. For
information about the DS1 and HDSL2 Alarm screens, see
page 32, respectively.
5 Press L to clear the screen.
6 Press Y to confirm.
To clear ALL history, alarm, and event log screens by this method:
1 Press C to select the Config screen.
2 Use the ↑ and
3 Press
ENTER
4 Press Y to clear all screens.
H2TU-C-202 List 7G
E to select the Event Log screen, then press
to select either interface (H2TU-C DS1, H2TU-R DS1, H2TU-C HDSL2, or
ENTER .
to select the type of statistics (Current, Alarm History, 25-Hour History,
↓ arrow keys to select Master Clear (see
to activate.
Figure 11. Config Menu - Master Clear
June 6, 2003
L to clear the screen.
ENTER after your selection.
Table 16 on page 30
Figure 11).
Provisioning
and Table 17 on
25
