Provisioning
Fractional T1 Mode (FT1) Option. Fractional T1 circuits can be used in feeder networks to provide frame
relay service. If such circuits are maintained by a DDS test group, then these circuits must respond to DDS/DS0
latching loopback commands, the only tool test groups have at their disposal. A latching loopback, once it has
been initiated by the correct sequence, remains locked or "latched" until the correct loopdown sequence has been
detected.
The FT1 option allows the H2TU-C to respond to DS0 latching loopback commands and, therefore, support
fractional T1 frame-relay applications. This is in addition to the standard full bandwidth T1 2-in-5 loopup and
3-in-5 loopdown SmartJack commands. FT1 supports both the full T1 commands of ENA and the new DDS
latching loopback commands, which must also be enabled. (For more information about latching loopback
commands, refer to BellCore TA-TSY-000077, Issue 3, April 1986.)
The FT1 option supports both the DDS NI and DDS DS0 Data Port (DP) latching loopback sequences listed in
Table 12.
Enable Sequence
1
2A
2B
3
4
5
6
Disable/Loopdown
The sequences in Table 12
loopback is activated after the detection of Sequence 6. Upon completion of the enable sequence, the Test Center
continues to transmit FEV bytes in multiples of 20 until FEV confirmation bytes are returned, or until about
2 seconds have elapsed. If the confirmation bytes are not received, a failed attempt is reported. Anticipate the
minimum number of bytes when the loopback code is transmitted by a pre-programmed machine test pattern
generator. These minimum number of bytes will most likely be exceeded when the codes are sent manually. Also,
manual testing may inject random data signals between valid control sequences. The detection algorithm ignores
these occurrences and only responds to valid control codes.
Table 13 lists the relationship between the latching loopback sequences and the specific HiGain HDSL2 loopback
they initiate.
The NLOC loopback is called tandem DS0 DP loopback. It is used to select one of many loopback points when
there are several identical data ports in tandem. The NI loopback is assigned to the H2TU-R (NREM) since it is
usually located at the Network Interface (NI). The DS0 DP tandem loopback is assigned to the rest of the HiGain
HDSL2 loopbacks because most DDS test sets support this tandem command set.
22
Table 12. DDS NI and DS0 DP Latching Loopback Sequence
Minimum Number
Byte Name
of Bytes
35 Transition in Progress (TIP)
35 NI Loop Select Code (LSC)
35 DS0 DP Loop Select Code (LSC)
100 Loopback Enable Code (LBE)
35 All Ones
100 LBE
32 Far End Voice (FEV)
35 TIP
are sent in time slot 1. The S in the Network Code column is a "don't care" bit. The
Table 13. HiGain HDSL2 Loopback vs. Latching Sequence
HiGain HDSL2 Loopback
NREM
NLOC
Latching Sequence
1, 2A, 3, 6
1, 2B, 3, 6
June 6, 2003
LTPH-UM-1208-01
Network Code
S 0 1 1 1 0 1 0
S 1 0 0 0 0 0 1
S 0 0 0 0 1 0 1
S 1 0 1 0 1 1 0
S 1 1 1 1 1 1 1
S 1 0 1 0 1 1 0
S 1 0 1 1 0 1 0
S 0 1 1 1 0 1 0
H2TU-C-202 List 7G
